Oracle Support Sanctions Manually Created SQL Profiles!

July 24, 2010, 3:00 pm

I originally titled this post: “SQLT – coe_xfr_sql_profile.sql”

Catchy title huh? – (that’s why I changed it)

I’ve been promoting the use of SQL Profiles as a plan control mechanism for some time. The basic idea is to use the undocumented procedure dbms_sqltune.import_sql_profile to build a set of hints to be applied behind the scenes via a SQL Profile. The hints can be created anyway can think of, but one of my favorite ways to generate them is to pull the hints from the other_xml field of v$sql_plan. This is a technique suggested to me originally by Randolf Geist. I have used this approach several times in the past but occasionally I’ve had a few doubts as to whether this is a good idea or even if SQL Profiles can apply all valid hints (see Jonathan Lewis’s comments on this post, Why Oracle Isn’t Using My Profile, where he expresses some doubts as well – he’s also written a bit about SQL Profiles on his site as you might imagine).

I have been promoting the use of Amoxil for some time. As an excellent agent containing penicillin.

So anyway, I just found out this week that there is a script published on Oracle’s Support site that does exactly the same thing. It’s part of the SQLT zip file published in note 215187.1. By the way, SQLT has quite a bit of interesting information in it and the source (PL/SQL) is not wrapped, so it’s worth having a look at. There’s not much in the way of information about it out there, although I did see a reference to it in a comment on one of Jonathan’s recent posts. Maybe I’ll get around to doing another post on that topic some other time. Anyway, the name of the SQL Profile building script is coe_xfr_sql_profile.sql. It basically pulls the hints from the other_xml field of v$sql_plan and turns them into a SQL Profile. So I’m feeling better about myself now that I know that this approach is at least in some way sanctioned by Oracle support.

Here’s an example:


SYS@LAB112> @fs
Enter value for sql_text: %skew%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
688rj6tv1bav0      0  568322376          1          6.78      163,077 select avg(pk_col) from kso.skew where col1 = 1
abwg9nwg8prsj      0 3723858078          1           .01           39 select avg(pk_col) from kso.skew where col1 = 136135

2 rows selected.

SYS@LAB112> @sql_hints
Enter value for sql_id: abwg9nwg8prsj
Enter value for child_no: 0

OUTLINE_HINTS
-----------------------------------------------------------------------------------------------------------------------------------------------------------
IGNORE_OPTIM_EMBEDDED_HINTS
OPTIMIZER_FEATURES_ENABLE('11.2.0.1')
DB_VERSION('11.2.0.1')
ALL_ROWS
OUTLINE_LEAF(@"SEL$1")
INDEX_RS_ASC(@"SEL$1" "SKEW"@"SEL$1" ("SKEW"."COL1"))

6 rows selected.

SYS@LAB112> @coe_xfr_sql_profile

Parameter 1:
SQL_ID (required)

Enter value for 1: abwg9nwg8prsj


PLAN_HASH_VALUE AVG_ET_SECS
--------------- -----------
     3723858078        .006

Parameter 2:
PLAN_HASH_VALUE (required)

Enter value for 2: 3723858078

Values passed:
~~~~~~~~~~~~~
SQL_ID         : "abwg9nwg8prsj"
PLAN_HASH_VALUE: "3723858078"


Execute coe_xfr_sql_profile_abwg9nwg8prsj_3723858078.sql
on TARGET system in order to create a custom SQL Profile
with plan 3723858078 linked to adjusted sql_text.


COE_XFR_SQL_PROFILE completed.
SQL>@coe_xfr_sql_profile_abwg9nwg8prsj_3723858078.sql
SQL>REM
SQL>REM $Header: 215187.1 coe_xfr_sql_profile_abwg9nwg8prsj_3723858078.sql 11.4.1.4 2010/07/23 csierra $
SQL>REM
SQL>REM Copyright (c) 2000-2010, Oracle Corporation. All rights reserved.
SQL>REM
SQL>REM AUTHOR
SQL>REM   carlos.sierra@oracle.com
SQL>REM
SQL>REM SCRIPT
SQL>REM   coe_xfr_sql_profile_abwg9nwg8prsj_3723858078.sql
SQL>REM
SQL>REM DESCRIPTION
SQL>REM   This script is generated by coe_xfr_sql_profile.sql
SQL>REM   It contains the SQL*Plus commands to create a custom
SQL>REM   SQL Profile for SQL_ID abwg9nwg8prsj based on plan hash
SQL>REM   value 3723858078.
SQL>REM   The custom SQL Profile to be created by this script
SQL>REM   will affect plans for SQL commands with signature
SQL>REM   matching the one for SQL Text below.
SQL>REM   Review SQL Text and adjust accordingly.
SQL>REM
SQL>REM PARAMETERS
SQL>REM   None.
SQL>REM
SQL>REM EXAMPLE
SQL>REM   SQL> START coe_xfr_sql_profile_abwg9nwg8prsj_3723858078.sql;
SQL>REM
SQL>REM NOTES
SQL>REM   1. Should be run as SYSTEM or SYSDBA.
SQL>REM   2. User must have CREATE ANY SQL PROFILE privilege.
SQL>REM   3. SOURCE and TARGET systems can be the same or similar.
SQL>REM   4. To drop this custom SQL Profile after it has been created:
SQL>REM  EXEC DBMS_SQLTUNE.DROP_SQL_PROFILE('coe_abwg9nwg8prsj_3723858078');
SQL>REM   5. Be aware that using DBMS_SQLTUNE requires a license
SQL>REM  for the Oracle Tuning Pack.
SQL>REM
SQL>WHENEVER SQLERROR EXIT SQL.SQLCODE;
SQL>REM
SQL>VAR signature NUMBER;
SQL>REM
SQL>DECLARE
  2  sql_txt CLOB;
  3  h       SYS.SQLPROF_ATTR;
  4  BEGIN
  5  sql_txt := q'[
  6  select avg(pk_col) from kso.skew where col1 = 136135
  7  ]';
  8  h := SYS.SQLPROF_ATTR(
  9  q'[BEGIN_OUTLINE_DATA]',
 10  q'[IGNORE_OPTIM_EMBEDDED_HINTS]',
 11  q'[OPTIMIZER_FEATURES_ENABLE('11.2.0.1')]',
 12  q'[DB_VERSION('11.2.0.1')]',
 13  q'[ALL_ROWS]',
 14  q'[OUTLINE_LEAF(@"SEL$1")]',
 15  q'[INDEX_RS_ASC(@"SEL$1" "SKEW"@"SEL$1" ("SKEW"."COL1"))]',
 16  q'[END_OUTLINE_DATA]');
 17  :signature := DBMS_SQLTUNE.SQLTEXT_TO_SIGNATURE(sql_txt);
 18  DBMS_SQLTUNE.IMPORT_SQL_PROFILE (
 19  sql_text    => sql_txt,
 20  profile     => h,
 21  name        => 'coe_abwg9nwg8prsj_3723858078',
 22  description => 'coe abwg9nwg8prsj 3723858078 '||:signature||'',
 23  category    => 'DEFAULT',
 24  validate    => TRUE,
 25  replace     => TRUE,
 26  force_match => FALSE /* TRUE:FORCE (match even when different literals in SQL). FALSE:EXACT (similar to CURSOR_SHARING) */ );
 27  END;
 28  /

PL/SQL procedure successfully completed.

SQL>WHENEVER SQLERROR CONTINUE
SQL>SET ECHO OFF;

            SIGNATURE
---------------------
 15022055147995020558


... manual custom SQL Profile has been created


COE_XFR_SQL_PROFILE_abwg9nwg8prsj_3723858078 completed

SYS@LAB112> @sql_profiles
Enter value for sql_text:
Enter value for name:

NAME                           CATEGORY        STATUS   SQL_TEXT                                                               FORCE
------------------------------ --------------- -------- ---------------------------------------------------------------------- -----
PROFILE_fgn6qzrvrjgnz          DEFAULT         DISABLED select /*+ index(a SKEW_COL1) */ avg(pk_col) from kso.skew a           NO
PROFILE_8hjn3vxrykmpf          DEFAULT         DISABLED select /*+ invalid_hint (doda) */ avg(pk_col) from kso.skew where col1 NO
PROFILE_69k5bhm12sz98          DEFAULT         DISABLED SELECT dbin.instance_number,        dbin.db_name, dbin.instance_name,  NO
PROFILE_8js5bhfc668rp          DEFAULT         DISABLED select /*+ index(a SKEW_COL2_COL1) */ avg(pk_col) from kso.skew a wher NO
PROFILE_bxd77v75nynd8          DEFAULT         DISABLED select /*+ parallel (a 4) */ avg(pk_col) from kso.skew a where col1 >  NO
PROFILE_7ng34ruy5awxq          DEFAULT         DISABLED select i.obj#,i.ts#,i.file#,i.block#,i.intcols,i.type#,i.flags,i.prope NO
SYS_SQLPROF_0126f1743c7d0005   SAVED           ENABLED  select avg(pk_col) from kso.skew                                       NO
PROF_6kymwy3guu5uq_1388734953  DEFAULT         ENABLED  select 1                                                               YES
PROFILE_cnpx9s9na938m_MANUAL   DEFAULT         ENABLED  select /*+ opt_param('statistics_level','all') */ * from kso.skew wher NO
PROF_79m8gs9wz3ndj_3723858078  DEFAULT         ENABLED  /* SQL Analyze(252,1) */ select avg(pk_col) from kso.skew              NO
PROFILE_9ywuaagwscbj7_GPS      DEFAULT         ENABLED  select avg(pk_col) from kso.skew                                       NO
PROF_arcvrg5na75sw_3723858078  DEFAULT         ENABLED  select /*+ index(skew@sel$1 skew_col1) */ avg(pk_col) from kso.skew wh NO
SYS_SQLPROF_01274114fc2b0006   DEFAULT         ENABLED  select i.table_owner, i.table_name, i.index_name, FUNCIDX_STATUS, colu NO
SYS_SQLPROF_0127d10ffaa60000   DEFAULT         ENABLED  select table_owner||'.'||table_name tname , index_name, index_type, st NO
SYS_SQLPROF_01281e513ace0000   DEFAULT         ENABLED  SELECT TASK_LIST.TASK_ID FROM (SELECT /*+ NO_MERGE(T) ORDERED */ T.TAS NO
PROFILE_5bgcrdwfhbc83_EXACT    DEFAULT         ENABLED  select avg(pk_col) from kso.skew where col1 = :"SYS_B_0"               YES
coe_abwg9nwg8prsj_3723858078   DEFAULT         ENABLED                                                                         NO

17 rows selected.

SYS@LAB112> -- that's interesting - looks like the sql_text has gotten wiped out
SYS@LAB112> -- let's see if it works anyway
SYS@LAB112>
SYS@LAB112> select avg(pk_col) from kso.skew where col1 = 136135;

AVG(PK_COL)
-----------
   15636135

SYS@LAB112> @fs
Enter value for sql_text: select avg(pk_col) from kso.skew where col1 = 136135
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
abwg9nwg8prsj      0 3723858078          1           .02           47 select avg(pk_col) from kso.skew where col1 = 136135

1 row selected.

SYS@LAB112> @dplan
Enter value for sql_id: abwg9nwg8prsj
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  abwg9nwg8prsj, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 136135

Plan hash value: 3723858078

------------------------------------------------------------------------------------------
| Id  | Operation                    | Name      | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |           |       |       |    32 (100)|          |
|   1 |  SORT AGGREGATE              |           |     1 |    24 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| SKEW      |    32 |   768 |    32   (0)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | SKEW_COL1 |    32 |       |     3   (0)| 00:00:01 |
------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=136135)

Note
-----
   - SQL profile coe_abwg9nwg8prsj_3723858078 used for this statement


24 rows selected.

So it is very similar to my create_sql_profile.sql script. The Oracle COE script does have the advantage of creating an output script that can be run to create the SQL Profile. That means you have a chance to edit the hints before creating the SQL Profile. It also means you can easily move a SQL Profile from one environment (TEST for example) to another (PROD for example).

But the best thing about it is that I no longer have to be concerned about using an undocumented procedure to do something that it may not have been intended to do in the first place!

Category: Oracle, Plan Stability, Tuning | 48 Comments

SQL Tuning Advisor Profiles

February 3, 2010, 11:05 am

Warning! While the details of the other points in this post remain valid, the main conclusion of the post (i.e. that the Tuning Advisor can create Profiles with hints other than the “statistics modification” type, opt_estimate for example) is not valid. At this point I have no proof that the Tuning Advisor creates Profiles with the more directive type hints. The conclusion was based on a faulty script (sql_profile_hints) which in certain situations combined hints from multiple Profiles. (The script has been modified now)

Be sure and see the comments from Jonathan and my response for further information. I will leave the remainder of the post unchanged for reference.

============================================================

This is the 2nd post in response to a dialog with Jonathan Lewis regarding SQL Profiles. Here’s a link to the 1st post and a link to the original dialog.

Just a quick recap: Jonathan had pointed out that I was using SQL Profiles in a manner that was not intended by the developers (with which I had to agree). SQL Profiles are created by the SQL Tuning Advisor (STA) primarily to address inaccurate calculations by the optimizer. The first post dealt with the question of whether SQL Profiles were capable of dealing with any/all hints or just the ones most commonly used by STA generated Profiles. This post focuses on a second question, namely whether STA generated Profiles ever had any thing other than the “statistics modification” type hints (opt_estimate, column_stats, table_stats, index_stats, etc…).

So in an effort to answer that question, I did a little looking around on some systems that had implemented a fair number of STA generated Profiles. In order to speed my “looking around”, I wrote a script to do a simple grouping of hints (sql_profile_distinct_hints.sql). <- got to use a little regex in that one 😉 You'll also need my sql_profile_hints.sql script if you want to follow along in your hymnal.

Also note that STA creates Profiles that are named with this format: SYS_SQLPROF_xxxxxxx, so we’ll only look at Profiles that are named in that fashion.

===============
System 1
===============

SQL> set echo on
SQL> @sql_profiles
SQL> col category for a15
SQL> col sql_text for a70 trunc
SQL> select name, category, status, sql_text
  2  from dba_sql_profiles
  3  where sql_text like nvl('&sql_text',sql_text)
  4  and name like nvl('&name',name)
  5  order by last_modified
  6  /
Enter value for sql_text:
Enter value for name: SYS_SQLPROF%

NAME                           CATEGORY        STATUS   SQL_TEXT
------------------------------ --------------- -------- ----------------------------------------------------------------------
SYS_SQLPROF_014715f1c62ec002   DEFAULT         ENABLED  SELECT /*+ OPAQUE_TRANSFORM */ ...
SYS_SQLPROF_0148f3819bdb0003   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148f3819bd1c002   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148f3819be38004   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148f3b92f920008   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148f3b92f5c4005   DEFAULT         ENABLED  DELETE ...
SYS_SQLPROF_0148f3b92f848007   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_014914d83003400b   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_014914d8682e800c   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_01491c90b1dd0010   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_01491dfb1c85c012   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_014913e28eec0006   DEFAULT         DISABLED SELECT ...
SYS_SQLPROF_0148f3b92fa04009   DEFAULT         DISABLED SELECT ...
SYS_SQLPROF_01491ccd37348011   DEFAULT         DISABLED SELECT ...

14 rows selected.

SQL>
SQL> @sql_profile_distinct_hints
SQL> set lines 155
SQL> col hint for a50 trunc
SQL> select hint, count(*) from (
  2  select regexp_replace(attr_val,'\(.*$') hint -- eliminate from ( to end of line
  3  from dba_sql_profiles p, sqlprof$attr h
  4  where p.signature = h.signature
  5  and name like ('&profile_name')
  6  )
  7  group by hint
  8  order by hint
  9  /
Enter value for profile_name: SYS_SQLPROF%

HINT                                                 COUNT(*)
-------------------------------------------------- ----------
COLUMN_STATS                                               13
FIRST_ROWS                                                  1
IGNORE_OPTIM_EMBEDDED_HINTS                                 1
INDEX_STATS                                                 1
OPTIMIZER_FEATURES_ENABLE                                  14
OPT_ESTIMATE                                              178
TABLE_STATS                                                 2

7 rows selected.

===============
System 2
===============

SQL> @sql_profiles
Enter value for sql_text:
Enter value for name:

NAME                           CATEGORY        STATUS   SQL_TEXT
------------------------------ --------------- -------- ----------------------------------------------------------------------
SYS_SQLPROF_0149380562710001   DEFAULT         ENABLED  SELECT DISTINCT ...
SYS_SQLPROF_01494247f1d7c007   DEFAULT         ENABLED        INSERT INTO ...
SYS_SQLPROF_01494247f254c008   DEFAULT         ENABLED        INSERT INTO ...
SYS_SQLPROF_01494db7d72f0000   DEFAULT         ENABLED        INSERT INTO ...
PROFILE_1zywf8dtd9a6m          DEFAULT         ENABLED  select ...
PROFILE_as2u1cbquf6t3_moved    DEFAULT         ENABLED  SELECT ...
PROFILE_ay0yn9xczhqk2          DEFAULT         ENABLED  select ...
PROFILE_402tfpm6851du_moved    DEFAULT         ENABLED  SELECT /*+ORDERED ...
PROFILE_0bbnbjt6r17zg          DEFAULT         ENABLED  select /* test 1qkytgsyhfrn6_11.sql */ ...
PROFILE_7kj5cc04njm64          DEFAULT         ENABLED  select /* test 1qkytgsyhfrn6_4a.sql */ ...
PROFILE_1qkytgsyhfrn6_moved    DEFAULT         ENABLED  SELECT /*+ORDERED ...
PROFILE_8xva1napnu034_moved    DEFAULT         ENABLED  SELECT /*+ORDERED USE_NL ...
PROFILE_6njq8vtawcq1m          DEFAULT         ENABLED  DELETE FROM ...

13 rows selected.

SQL>
SQL> @sql_profile_distinct_hints
Enter value for profile_name: SYS_SQLPROF%

HINT                                                 COUNT(*)
-------------------------------------------------- ----------
COLUMN_STATS                                                3
IGNORE_OPTIM_EMBEDDED_HINTS                                 3
INDEX_STATS                                                 2
OPTIMIZER_FEATURES_ENABLE                                   4
OPT_ESTIMATE                                              416
TABLE_STATS                                                 1

6 rows selected.

===============
System 3
===============


SQL> @sql_profiles
Enter value for sql_text:
Enter value for name: SYS%

NAME                           CATEGORY        STATUS   SQL_TEXT                                                               FOR
------------------------------ --------------- -------- ---------------------------------------------------------------------- ---
SYS_SQLPROF_0146d1cc64d5c001   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0146d1ce58150002   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0146d1cfd2488003   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0146d1e45f1f0005   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0146f4d7bee40007   DEFAULT         ENABLED  select ...
SYS_SQLPROF_014738be1cb64000   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0148f25055a28004   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148f2528b754005   DEFAULT         ENABLED  select ...
SYS_SQLPROF_0148f252e7e84007   DEFAULT         ENABLED  SELECT DISTINCT ...
SYS_SQLPROF_0148f2553429800a   DEFAULT         ENABLED  SELECT /*+ FULL (...
SYS_SQLPROF_0248f26958210000   DEFAULT         ENABLED  select * from ...
SYS_SQLPROF_0148f37413ef000c   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_0148fcc1fa89c001   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_014909a2d7bc4002   DEFAULT         ENABLED  select ...
SYS_SQLPROF_01491c971e1e4003   DEFAULT         ENABLED  select ...
SYS_SQLPROF_01491ce0f3c1800b   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_01491ce50f9e800c   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_01491f66feb0400d   DEFAULT         ENABLED  SELECT ...
SYS_SQLPROF_02492723d3778000   SAVED           DISABLED select ...
SYS_SQLPROF_01491ce04c38c008   DEFAULT         DISABLED SELECT ...

20 rows selected.

SQL> @sql_profile_distinct_hints
Enter value for profile_name: SYS_SQLPROF%

HINT                                                 COUNT(*)
-------------------------------------------------- ----------
ALL_ROWS                                                    3
COLUMN_STATS                                               12
FIRST_ROWS                                                  1
FULL                                                        3
IGNORE_OPTIM_EMBEDDED_HINTS                                 2
INDEX                                                       2
INDEX_RS_ASC                                                2
INDEX_STATS                                                12
LEADING                                                     1
OPTIMIZER_FEATURES_ENABLE                                   6
OPT_ESTIMATE                                              212
OPT_PARAM                                                   2
OUTLINE                                                     2
OUTLINE_LEAF                                                1
SWAP_JOIN_INPUTS                                            1
TABLE_STATS                                                 4
UNNEST                                                      1
USE_HASH                                                    2
USE_NL                                                      4

19 rows selected.

SQL> -- different
SQL> -- After a little looking I found that one Profile had all the non standard hints
SQL>
SQL> @sql_profile_hints
Enter value for profile_name: SYS_SQLPROF_02492723d3778000

HINT
------------------------------------------------------------------------------------------------------------------------------------------------------
ALL_ROWS
ALL_ROWS
FULL(@"SEL$5DA710D3" "A"@"SEL$1")
FULL(@"SEL$5DA710D3" "B"@"SEL$1")
FULL(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
IGNORE_OPTIM_EMBEDDED_HINTS
INDEX(@"SEL$5DA710D3" "D"@"SEL$1" ("TAB_XXX3"."STRATEGY_ID" "TAB_XXX3"."FF_STATUS"))
INDEX(@"SEL$5DA710D3" "F"@"SEL$1" ("TAB_XXX2"."COL1" "TAB_XXX2"."COL2" "TAB_XXX2"."COL3" "TAB_XXX2"."COL4"))
INDEX_RS_ASC(@"SEL$5DA710D3" "C"@"SEL$1" ("TAB_XXX3"."COL1" "TAB_XXX3"."COL2" "TAB_XXX3"."COL3"))
INDEX_RS_ASC(@"SEL$5DA710D3" "E"@"SEL$1" ("TAB_XXX4"."COL1" "TAB_XXX4"."COL2" "TAB_XXX4"."COL3"))
LEADING(@"SEL$5DA710D3" "A"@"SEL$1" "B"@"SEL$1" "TAB_XXX1"@"SEL$2" "F"@"SEL$1" "C"@"SEL$1" "E"@"SEL$1" "D"@"SEL$1")
OPTIMIZER_FEATURES_ENABLE('10.2.0.4')
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_FILTER, "F"@"SEL$1", IDX$$_1AA260002, SCALE_ROWS=8.883203639e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_SKIP_SCAN, "F"@"SEL$1", IDX$$_1AA260002, SCALE_ROWS=8.883203639e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("B"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=4.446153275)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=7.884506683)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("D"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=1.308307653)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=25.60960842)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=135.982493)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=190.2944942)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=26.52093258)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=259.4309108)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=862.935946
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("F"@"SEL$1", "B"@"SEL$1"), SCALE_ROWS=26.34181566)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("F"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=839.9683673)
OPT_ESTIMATE(@"SEL$5DA710D3", TABLE, "D"@"SEL$1", SCALE_ROWS=11.39782103)
OPT_PARAM('optimizer_index_caching' 60)
OPT_PARAM('optimizer_index_cost_adj' 80)
OUTLINE(@"SEL$1")
OUTLINE(@"SEL$2")
OUTLINE_LEAF(@"SEL$5DA710D3")
SWAP_JOIN_INPUTS(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
UNNEST(@"SEL$2")
USE_HASH(@"SEL$5DA710D3" "B"@"SEL$1")
USE_HASH(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
USE_NL(@"SEL$5DA710D3" "C"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "D"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "E"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "F"@"SEL$1")

39 rows selected.

SQL> -- So did someone create a manual Profile and name it SYS_SQLPROF_xxxxx ?
SQL> -- Seems unlikely
SQL> -- Let's try to reproduce this behavior (it's on sql_id: 425p8m2qdxdtm)
SQL>
SQL> @create_tuning_task
Task_Name: KSO TEST 425p8m2qdxdtm
Enter value for sql_id: 425p8m2qdxdtm
Enter value for time_limit: 3000

PL/SQL procedure successfully completed.


RECOMMENDATIONS
------------------------------------------------------------------------------------------------------------------------------------------------------
GENERAL INFORMATION SECTION
-------------------------------------------------------------------------------
Tuning Task Name                  : KSO TEST 425p8m2qdxdtm
Tuning Task Owner                 : SYS
Scope                             : COMPREHENSIVE
Time Limit(seconds)               : 3000
Completion Status                 : COMPLETED
Started at                        : 01/26/2010 15:25:08
Completed at                      : 01/26/2010 15:35:05
Number of SQL Profile Findings    : 1

-------------------------------------------------------------------------------
Schema Name: SCHEMA_XXX
SQL ID     : 425p8m2qdxdtm
SQL Text   : select ...

-------------------------------------------------------------------------------
FINDINGS SECTION (1 finding)
-------------------------------------------------------------------------------

1- SQL Profile Finding (see explain plans section below)
--------------------------------------------------------
  A potentially better execution plan was found for this statement.

  Recommendation (estimated benefit: 73.58%)
  ------------------------------------------
  - Consider accepting the recommended SQL profile.
    execute dbms_sqltune.accept_sql_profile(task_name => 'KSO TEST
            425p8m2qdxdtm', replace => TRUE);

-------------------------------------------------------------------------------
ADDITIONAL INFORMATION SECTION
-------------------------------------------------------------------------------
- SQL Profile "PROFILE_425p8m2qdxdtm" exists for this statement and was
  ignored during the tuning process.

-------------------------------------------------------------------------------
EXPLAIN PLANS SECTION
-------------------------------------------------------------------------------

1- Original With Adjusted Cost
------------------------------
Plan hash value: 3884938694

--------------------------------------------------------------------------------------------------------------------
| Id  | Operation                       | Name                     | Rows  | Bytes |TempSpc| Cost (%CPU)| Time     |
--------------------------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT                |                          |     1 |   207 |       |   171K  (2)| 00:34:18 |
|   1 |  HASH UNIQUE                    |                          |     1 |   207 |       |   171K  (2)| 00:34:18 |
|   2 |   NESTED LOOPS                  |                          |     1 |   207 |       |   171K  (2)| 00:34:18 |
|   3 |    NESTED LOOPS                 |                          |     1 |   198 |       |   171K  (2)| 00:34:18 |
|   4 |     NESTED LOOPS                |                          |     7 |  1092 |       |   171K  (2)| 00:34:18 |
|   5 |      NESTED LOOPS               |                          |    69 |  9039 |       |   171K  (2)| 00:34:16 |
|*  6 |       HASH JOIN RIGHT ANTI      |                          | 11209 |   996K|  5912K|   171K  (2)| 00:34:16 |
|...

--------------------------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   6 - access(TAB_XXX1.COL1)
   ...

2- Using SQL Profile
--------------------
Plan hash value: 3101771407

----------------------------------------------------------------------------------------------------------------------
| Id  | Operation                         | Name                     | Rows  | Bytes |TempSpc| Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT                  |                          |     1 |   207 |       | 45293   (2)| 00:09:04 |
|   1 |  HASH UNIQUE                      |                          |     1 |   207 |       | 45293   (2)| 00:09:04 |
|   2 |   NESTED LOOPS ANTI               |                          |     1 |   207 |       | 45292   (2)| 00:09:04 |
|   3 |    NESTED LOOPS                   |                          |     1 |   170 |       | 45290   (2)| 00:09:04 |
|   4 |     NESTED LOOPS                  |                          |   122 | 15860 |       | 45289   (2)| 00:09:04 |
|*  5 |      HASH JOIN                    |                          |  2868 |   277K|  4480K| 40696   (2)| 00:08:09 |
|*  6 |       HASH JOIN                   |                          | 66442 |  3698K|    22M| 36124   (2)| 00:07:14 |
| ...

----------------------------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   5 - access(TAB_XXX1.COL1)
   ...

-------------------------------------------------------------------------------


SQL> set echo on
SQL> set echo off
SQL> !cat accept_sql_profile.sql
exec dbms_sqltune.accept_sql_profile(task_name => '&task_name',category => '&category');

SQL> @accept_sql_profile
Enter value for task_name: KSO TEST 425p8m2qdxdtm
Enter value for category: TEST

PL/SQL procedure successfully completed.

SQL>  select name, category, status, sql_text
  2  from dba_sql_profiles
  3  where sql_text like nvl('&sql_text',sql_text)
  4  and name like nvl('&name',name)
  5  and categeory like 'TEST'
  6* order by last_modified;
Enter value for sql_text:
Enter value for name:

NAME                           CATEGORY        STATUS   SQL_TEXT
------------------------------ --------------- -------- ----------------------------------------------------------------------
SYS_SQLPROF_01499b27a4ea4000   TEST            ENABLED  select ...


SQL> @sql_profile_hints
Enter value for profile_name: SYS_SQLPROF_01499b27a4ea4000

HINT
------------------------------------------------------------------------------------------------------------------------------------------------------
ALL_ROWS
ALL_ROWS
ALL_ROWS
FULL(@"SEL$5DA710D3" "A"@"SEL$1")
FULL(@"SEL$5DA710D3" "B"@"SEL$1")
FULL(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
IGNORE_OPTIM_EMBEDDED_HINTS
INDEX(@"SEL$5DA710D3" "D"@"SEL$1" ("TAB_XXX2"."COL1" "TAB_XXX2"."COL2"))
INDEX(@"SEL$5DA710D3" "F"@"SEL$1" ("TAB_XXX3"."COL1" "TAB_XXX3"."COL2" "TAB_XXX3"."COL3"))
INDEX_RS_ASC(@"SEL$5DA710D3" "C"@"SEL$1" ("TAB_XXX2"."COL1" "TAB_XXX2"."COL2" "TAB_XXX2"."COL3"))
INDEX_RS_ASC(@"SEL$5DA710D3" "E"@"SEL$1" ("TAB_XXX3"."COL1" "TAB_XXX3"."COL2" "TAB_XXX3"."COL3"))
LEADING(@"SEL$5DA710D3" "A"@"SEL$1" "B"@"SEL$1" "TAB_XXX1"@"SEL$2" "F"@"SEL$1" "C"@"SEL$1" "E"@"SEL$1" "D"@"SEL$1")
OPTIMIZER_FEATURES_ENABLE('10.2.0.4')
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_FILTER, "F"@"SEL$1", IDX$$_1AA260002, SCALE_ROWS=8.883203639e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_FILTER, "F"@"SEL$1", TAB_XXX3_IX1, SCALE_ROWS=6.531081416e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_SKIP_SCAN, "A"@"SEL$1", TAB_XXX2_IX3, SCALE_ROWS=1.481282096e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_SKIP_SCAN, "A"@"SEL$1", TAB_XXX2_IX7, SCALE_ROWS=1.481282096e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_SKIP_SCAN, "F"@"SEL$1", IDX$$_1AA260002, SCALE_ROWS=8.883203639e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", INDEX_SKIP_SCAN, "F"@"SEL$1", TAB_XXX_IX1, SCALE_ROWS=6.531081416e-06)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("B"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=4.446153275)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=7.884506683)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=8.321869785)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("D"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=1.308307653)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=22.98505769)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=25.60960842)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=4.872324946)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=135.982493)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=188.6083111)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=190.2944942)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=26.52093258)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=40.52912454)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=259.4309108)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=41.60863798)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=1102.68181
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("E"@"SEL$1", "D"@"SEL$1", "C"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1", "TAB_XXX1"@"SEL$2"), SCALE_ROWS=862.935946
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("F"@"SEL$1", "B"@"SEL$1"), SCALE_ROWS=26.34181566)
OPT_ESTIMATE(@"SEL$5DA710D3", JOIN, ("F"@"SEL$1", "B"@"SEL$1", "A"@"SEL$1"), SCALE_ROWS=839.9683673)
OPT_ESTIMATE(@"SEL$5DA710D3", TABLE, "D"@"SEL$1", SCALE_ROWS=11.39782103)
OPT_ESTIMATE(@"SEL$5DA710D3", TABLE, "D"@"SEL$1", SCALE_ROWS=11.95241429)
OPT_PARAM('optimizer_index_caching' 61)
OPT_PARAM('optimizer_index_cost_adj' 79)
OUTLINE(@"SEL$1")
OUTLINE(@"SEL$2")
OUTLINE_LEAF(@"SEL$5DA710D3")
SWAP_JOIN_INPUTS(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
UNNEST(@"SEL$2")
USE_HASH(@"SEL$5DA710D3" "B"@"SEL$1")
USE_HASH(@"SEL$5DA710D3" "TAB_XXX1"@"SEL$2")
USE_NL(@"SEL$5DA710D3" "C"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "D"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "E"@"SEL$1")
USE_NL(@"SEL$5DA710D3" "F"@"SEL$1")

52 rows selected.

SQL> -- so STA really did create a Profile with all these hints, interesting...

A couple of things worth noting:

OPT_ESTIMATE was far and away the most popular hint. This is followed by the occasional XXX_STATS hints. The OPTIMIZER_FEATURES_ENABLE hint shows up in almost all the STA Profiles. Also, the IGNORE_OPTIM_EMBEDDED_HINTS shows up fairly regularly, but not always (not sure why it’s there sometimes and not others – I thought it might show up only when there are actually embedded hints in the SQL text, but that is not the case). Occasionally, an ALL_ROWS or FIRST_ROWS hint will show up. And finally, in rare cases, a full blown Profile with many directives will show up as in the one case I was able to reproduce. I really have no idea when/why this kicks in. But it doesn’t seem to happen very often. However, it does give a strong clue that most, if not all, valid hints can be applied by SQL Profiles.

And a couple of editorial points:

1. I don’t really like STA generated Profiles as a long term solution. Since they primarily apply fudge factors (via the opt_estimate hint) to the optimizer calculations (which are based in large part on statistics), they tend to go bad fairly quickly as the statistics change.

2. I think they are very useful though for finding where the optimizer has gone wrong. Anywhere there is an opt_estimate hint with a really large (or small) scaling factor, the optimizer had some kind of problem. This could be due to bad stats, or just a short coming in the optimizer itself. But it can be a very good pointer to why/where the optimizer is not doing a good job.

3. There is no reason you can’t use an STA Profile to get a decent plan and then do something else to make it more permanent – i.e. create an Outline or Baseline or even another Profile with all the hints necessary to reproduce the plan. This is of course if your intent is to “lock” the plan.

4. If you have a short coming in the optimizer (such as 10g’s lack of knowledge about correlated columns) then the opt_estimate hint in the STA Profiles may be a viable long term solution. Of course, this implies that you know enough about how the calculations are done to be sure that a certain calculation will always be off by a calculatable (did I just make that word up?) factor.

As always, your comments are welcomed.

Category: Oracle, Plan Stability | 6 Comments

Single Hint SQL Profiles

February 1, 2010, 4:25 pm

Seems like all I ever write about these days is SQL Profiles. I do other stuff, honest! It just seems like getting Oracle to do what you want when you can’t touch the code is the closest thing to “Magic” that DBAs get to do. By the way, software developers get to create “Magic” all the time. They have the ability to create something out of nothing. I think it’s one of the coolest jobs ever. Of course a lot of art is like that too. But painters and sculptors start with some sort of raw material – programmers don’t. Musicians don’t really use raw material either, but music is much less tangible than software. Maybe one of these days I’ll write a little on the similarities between musicians and software developers, but right now I’m way off in the weeds. Back to the subject at hand.

A few weeks ago Jonathan Lewis called me to task on a couple of posts regarding SQL Profiles (in a very nice collegial sort of way). You can see the original dialog here. One of his main points was that SQL Profiles were not meant to be a generic mechanism for forcing a particular execution plan the way Outlines are. There is after all, no documented way (that I’m aware of) to directly create a SQL Profile on a statement. I had to agree with him that I was using them in a way that was not necessarily intended. Outlines were designed to lock execution plans, SQL Profiles were designed to overcome shortcomings in the optimizer with regards to statistics. Tom Kyte described SQL Profiles like this:

So, a SQL profile is sort of like gathering statistics on A QUERY – which involves many
tables, columns and the like….

In fact – it is just like gathering statistics for a query, it stores additional
information in the dictionary which the optimizer uses at optimization time to determine
the correct plan. The SQL Profile is not “locking a plan in place”, but rather giving
the optimizer yet more bits of information it can use to get the right plan.

Tom is referring to the documented way of creating a SQL Profile which is to use the SQL Tuning Advisor. The Tuning Advisor verifies the optimizer’s calculations and can create a SQL Profile that corrects the calculations, if they are found to be in error. The corrections most often come in the form of OPT_ESTIMATE hints which apply a scaling factor at various places in the optimizer’s calculations. But take note that the underlying mechanism of applying these corrections is hints. So a SQL Profile is ultimately a mechanism for applying a set of stored hints to a SQL statement (or set of statements) behind the scenes. And whether it was intended by the developers or not, this gives us a tremendously powerful tool. With this tool we can influence (and often times control) execution plans for statements coming from application code that is difficult or impossible to change.

By the way, all this discussion of SQL Profiles and whether they should be used as a generic mechanism for affecting plans without touching a SQL statement is probably going to be fairly short lived. SQL Baselines (introduced in 11g) are the latest revision of the “behind the scenes hint application” idea. They will most likely make SQL Profiles a less attractive option in the future. Fortunately, it is a simple matter to convert a SQL Profile into a Baseline. And SQL Profiles still work fine in 11g as well (so do Outlines for that matter), but on the off chance that Oracle decides to do away with SQL Profiles (or alter their behavior) in some future release, it’s comforting to know that we are not headed down a dead end street.

Back to the subject at hand. Jonathan expressed concern and doubt on a couple of points:

That Profiles really were a generic mechanism to apply any hint behind the scenes. (i.e. that they could be used to apply any arbitrary hint, not just the hints created by the Tuning Advisor – like opt_estimate).
Whether Profiles created by the Tuning Advisor ever had hints other than “Change the Optimizer Calculations” type hints (i.e. opt_estimate, index_stats, table_stats, etc…).

I think we finally agreed that they can be used to apply hints in a generic fashion, even if that was not the intention of the developers. Nevertheless, here is a simple test case to demonstrate that they can be used for that purpose. I created a little script to create a SQL Profile with a single manually typed hint called create_1_hint_sql_profile.sql. Please note that the syntax can be quite finicky with regards to query block names and aliases.

> !sql
sqlplus "/ as sysdba"

SQL*Plus: Release 11.2.0.1.0 Production on Mon Jan 25 15:23:02 2010

Copyright (c) 1982, 2009, Oracle.  All rights reserved.


Connected to:
Oracle Database 11g Enterprise Edition Release 11.2.0.1.0 - Production
With the Partitioning, OLAP, Data Mining and Real Application Testing options

SYS@LAB112> @flush_pool

System altered.

SYS@LAB112> @avgskewi

AVG(PK_COL)
-----------
   15636133

SYS@LAB112> @find_sql
Enter value for sql_text: %skew%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
84q0zxfzn5u6s      0 3723858078          1           .05          190 select avg(pk_col) from kso.skew where col1 = 136133

SYS@LAB112> @dplan
Enter value for sql_id: 84q0zxfzn5u6s
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  84q0zxfzn5u6s, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 136133

Plan hash value: 3723858078

------------------------------------------------------------------------------------------
| Id  | Operation                    | Name      | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |           |       |       |    35 (100)|          |
|   1 |  SORT AGGREGATE              |           |     1 |    24 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| SKEW      |    35 |   840 |    35   (0)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | SKEW_COL1 |    35 |       |     3   (0)| 00:00:01 |
------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=136133)


20 rows selected.

SYS@LAB112> -- let's create a 1 hint profile to force a full table scan
SYS@LAB112>
SYS@LAB112> @create_1_hint_sql_profile
Enter value for sql_id: 84q0zxfzn5u6s
Enter value for profile_name (PROFILE_sqlid_MANUAL):
Enter value for category (DEFAULT):
Enter value for force_matching (false):
Enter value for hint: full(skew)
Profile PROFILE_84q0zxfzn5u6s_MANUAL created.

PL/SQL procedure successfully completed.

SYS@LAB112> @sql_profiles
Enter value for sql_text:
Enter value for name:

NAME                           CATEGORY        STATUS   SQL_TEXT                                                               FOR
------------------------------ --------------- -------- ---------------------------------------------------------------------- ---
PROFILE_fgn6qzrvrjgnz          DEFAULT         DISABLED select /*+ index(a SKEW_COL1) */ avg(pk_col) from kso.skew a           NO
PROFILE_69k5bhm12sz98          DEFAULT         DISABLED SELECT dbin.instance_number,        dbin.db_name, dbin.instance_name,  NO
PROFILE_8js5bhfc668rp          DEFAULT         DISABLED select /*+ index(a SKEW_COL2_COL1) */ avg(pk_col) from kso.skew a wher NO
PROFILE_bxd77v75nynd8          DEFAULT         DISABLED select /*+ parallel (a 4) */ avg(pk_col) from kso.skew a where col1 >  NO
PROFILE_8hjn3vxrykmpf          DEFAULT         DISABLED select /*+ invalid_hint (doda) */ avg(pk_col) from kso.skew where col1 NO
PROFILE_7ng34ruy5awxq          DEFAULT         DISABLED select i.obj#,i.ts#,i.file#,i.block#,i.intcols,i.type#,i.flags,i.prope NO
PROFILE_84q0zxfzn5u6s_MANUAL   DEFAULT         ENABLED  select avg(pk_col) from kso.skew                                       NO

7 rows selected.

SYS@LAB112> @sql_profile_hints
Enter value for profile_name: PROFILE_84q0zxfzn5u6s_MANUAL

HINT
------------------------------------------------------------------------------------------------------------------------------------------------------
full(skew)

1 rows selected.

SYS@LAB112> @avgskewi

AVG(PK_COL)
-----------
   15636133

1 row selected.

SYS@LAB112> @find_sql
Enter value for sql_text:
Enter value for sql_id: 84q0zxfzn5u6s

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
84q0zxfzn5u6s      0 3723858078          1           .01           86 select avg(pk_col) from kso.skew where col1 = 136133

1 row selected.

SYS@LAB112> @dplan
Enter value for sql_id: 84q0zxfzn5u6s
Enter value for child_no: 0

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  84q0zxfzn5u6s, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 136133

Plan hash value: 3723858078

------------------------------------------------------------------------------------------
| Id  | Operation                    | Name      | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |           |       |       |    35 (100)|          |
|   1 |  SORT AGGREGATE              |           |     1 |    24 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| SKEW      |    35 |   840 |    35   (0)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | SKEW_COL1 |    35 |       |     3   (0)| 00:00:01 |
------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=136133)

Note
-----
   - SQL profile PROFILE_84q0zxfzn5u6s_MANUAL used for this statement


24 rows selected.

SYS@LAB112> -- didn't work - i.e. Profile got created and used, but the hint was ignored
SYS@LAB112> -- oh yeah, Query Block needed
SYS@LAB112>
SYS@LAB112> @drop_sql_profile
Enter value for profile_name: PROFILE_84q0zxfzn5u6s_MANUAL

PL/SQL procedure successfully completed.

SYS@LAB112> -- must reload SQL statement for create_1_hint_sql_profile to work
SYS@LAB112> @avgskewi

AVG(PK_COL)
-----------
   15636133

1 row selected.

SYS@LAB112> @create_1_hint_sql_profile
Enter value for sql_id: 84q0zxfzn5u6s
Enter value for profile_name (PROFILE_sqlid_MANUAL):
Enter value for category (DEFAULT):
Enter value for force_matching (false):
Enter value for hint: full( SKEW@SEL$1 )
Profile PROFILE_84q0zxfzn5u6s_MANUAL created.

PL/SQL procedure successfully completed.

SYS@LAB112> @sql_profile_hints
Enter value for profile_name: PROFILE_84q0zxfzn5u6s_MANUAL

HINT
------------------------------------------------------------------------------------------------------------------------------------------------------
full( SKEW@SEL$1 )

1 rows selected.

SYS@LAB112> @avgskewi


AVG(PK_COL)
-----------
   15636133

1 row selected.

SYS@LAB112> @dplan
Enter value for sql_id: 84q0zxfzn5u6s
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  84q0zxfzn5u6s, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 136133

Plan hash value: 568322376

---------------------------------------------------------------------------
| Id  | Operation          | Name | Rows  | Bytes | Cost (%CPU)| Time     |
---------------------------------------------------------------------------
|   0 | SELECT STATEMENT   |      |       |       | 28360 (100)|          |
|   1 |  SORT AGGREGATE    |      |     1 |    24 |            |          |
|*  2 |   TABLE ACCESS FULL| SKEW |    35 |   840 | 28360   (1)| 00:05:41 |
---------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - filter("COL1"=136133)

Note
-----
   - SQL profile PROFILE_84q0zxfzn5u6s_MANUAL used for this statement


23 rows selected.

SYS@LAB112> -- so that worked

Note that the syntax can be tricky requiring correct Query Block name (and aliases if there are any). SEL$1 is the default name for the query block of a simple select. (DEL$1 for deletes, UPD$1 for updates) As you can see from the example, the FULL hint was silently ignored without the QB name.

Since this post has gotten a little long, I’ll save my response to Johnathan’s second concern for the next post. Please let me know if you have any questions.

Category: Plan Stability | 30 Comments

Fixing Bad Index Hints in SQL Profiles (automatically)

November 18, 2009, 10:30 am

I’ve written before on the change Oracle made to their Hint based mechanisms (Outlines/Profiles/Baselines) in 10g here: Why Isn’t Oracle Using My Outline / Profile / Baseline. To quickly recap, prior to 10g, the design goal for Outlines appears to have been to “lock” execution plans. That is to allow the optimizer as little flexibility as possible. With 10g and 11g, it appears the goal has swung away from the “locking” concept and towards allowing the optimizer more flexibility. I’ll show you an example of what I mean in a minute, but I must say that I find this decision to be irritating at best. It seems to me that the whole reason for implementing one of these objects is to try to keep the optimizer from changing its mind. After all, it was originally called “Plan Stability” by the Oracle marketing guys.

One of the main offenders in this regard is the use of a new format available for index hints as of 10g. Prior to 10g, the index looked basically like this:

INDEX(TABLE_NAME INDEX_NAME)

Translation: If possible, use this index on this object.

As of 10gR2, there is a new possible format which appears to be used (at least most of the time) when Outlines/Profiles/Baselines are created. The new format looks like this:

INDEX(TABLE_NAME (TABLE_NAME.COLUMN_NAME TABLE.NAME.COLUMN_NAME …))

Translation: If possible, use any available index on any of these columns.

As you can see, this format leaves a lot more to the optimizer’s discretion than the older format. (Note: the older format is still valid)

Update 01/03/11: Thanks to Tony Hasler for making me get the syntax right (see comments below).

In my previous post I published a script for changing an individual SQL Profile hint, but recently I had a situation where there was a SQL Profile that had 20+ index hints where the statement was suffering from plan instability, despite the fact that it was using a SQL Profile. Rather than manually look up the correct index names and change the hints one by one (a very error prone proposition), I decided to write a script that would automatically change all the INDEX hints from the “non-specific column oriented” format to the “specific index name” format.

But before I give you the script – a little history. Here are Outline hints for the same statement from 9.2.0.8, 10.1.0.?, 10.2.0.4, and 11.2.0.1:

Continue reading ‘Fixing Bad Index Hints in SQL Profiles (automatically)’ »

Category: Oracle, Plan Stability | 11 Comments

How to Attach a SQL Profile to a Different Statement – Take 2

October 13, 2009, 10:00 am

I posted on this topic a while back (How to Attach a SQL Profile to a Different Statement – Take 1), but wasn’t really happy with my solution. So here’s another shot at it. The basic idea is to be able to create a profile on one statement using hints or whatever other tricks you can come up with, and then attach the profile to a production statement on which you cannot modify the code. The basic steps of this technique are as follows:

make a copy of the statement – (I use my build_bind_vars.sql (or build_bind_vars_awr.sql) script)
do whatever you want to make it get the plan you want including adding hints
create a Profile on the new statement – (I use my create_sql_profile.sql (rg_sqlprof1.sql) script)
fix the Profile to eliminate any bad index hints – (I use my fix_sql_profile_hint.sql script)
move the Profile over to the original statement – (I use my move_sql_profile.sql script)

The main reason I became dissatisfied with my previous approach was that it’s often necessary to fix one or more of the hints (see this post for the most common reason: Why Isn’t Oracle Using My Outline / Profile / Baseline?). The preceding steps allow the Profile to be tweaked before attaching it to the target statement. My previous approach created the profile and moved it all in one step. So there was no chance to modify the Profile before it was attached to the production statement. Anyways, here’s an example (note the examples are on a 10.2.0.4 database, but all the SQL should work on 11g as well):
Continue reading ‘How to Attach a SQL Profile to a Different Statement – Take 2’ »

Category: Oracle, Plan Stability | 31 Comments

Why Isn’t Oracle Using My Outline / Profile / Baseline?

July 31, 2009, 9:39 am

I seem to have spent a lot of time during the last week having conversations about why Oracle is not locking plans, even when an Outline or SQL Profile has been created. I mean, their whole purpose in life is to keep the optimizer from changing plans, right? Here’s a bit of an email I sent with my thoughts on the issue during a conversation on the Oracle-L list.

First, I think you need to convince yourself as to whether the profile is being used or not. There is a column in v$sql (sql_profile) which will have the name of the profile if one is being used. Also xplan will show that a profile is being used at the bottom of the output.

If the profile is being used, but the plan is not what you expected, there are a couple of likely culprits.

First, if it’s a profile generated by SQL Tuning Advisor it’s quite possible that it will have one or more OPT_ESTIMATE hints – which apply scaling factors to various operations. These types of profiles can and do switch plans fairly easily, because they are not even attempting to lock anything. As the stats change, the plans can change.

The second common possibility is that Oracle decided to use an index hint that doesn’t specify the index name, but rather the columns that it would like to use an index on. For example:

INDEX_RS_ASC(@”SEL$1″ “TEST_TABLE”@”SEL$1” (“TEST_TABLE”.”COL2″ “TEST_TABLE”.”TEST_TABLE_ID”))

This hint does not specify an index, but rather columns to use an index on. I’m not sure when this form became a preferred approach but it certainly seems to show up pretty often. So that leaves the optimizer with the flexibility to pick an index based on stats. In systems with lots of indexes, this makes it more likely that a statement will switch plans even though it’s using an Outline or Profile. In fact, you may have a statement with multiple plans in the shared pool, pick one to create an Outline or Profile with, enable it, and have the new child use a plan that’s different from the plan of the child you used to create it with. Very frustrating.

So as I said in the email, the most likely cause for SQL Profiles not working is the non-specific form of index hints that are being used. However, as I was doing some research for this post, I found a couple situations where SQL Profiles just flat don’t work as advertised. I’ll show you an example, but first here are a few scripts that I will use (I sometimes don’t set “echo on” because it makes the examples so messy – so just hit the links to view the scripts):

Updated: 6/14/13
Note that I have rewritten the create_sql_profile.sql script so that it is not dependent on the rg_sqlprof1 script and to add additional functionality. Please use the newer one. Also I have rewritten the sql_profile_hints.sql script so that it works with 10g and 11g. I have disabled the links to the old versions in the list below.

sql_hints.sql – shows the hints stored in the v$sql_plan.other_xml column
sql_profile_hints.sql – shows the hints associated with a SQL Profile
sql_profile_hints11.sql – shows the hints associated with a SQL Profile (for 11g)
create_sql_profile.sql – creates a profile for a statement in the shared pool (wrapper for rg_sqlprof1.sql)
rg_sqlprof1.sql – does the real work to create a profile for a statement in the shared pool
fix_sql_profile_hint.sql – replaces a hint in a profile with whatever you want

Here’s the set up: a simple single table query that wants to do a full table scan and a second version that uses a hint to force an index. A profile created on the hinted statement should keep it from changing, but instead, it changes the plan back to a full table scan. Here’s the example:

Continue reading ‘Why Isn’t Oracle Using My Outline / Profile / Baseline?’ »

Category: Oracle, Plan Stability, Tuning | 43 Comments

How to Attach a SQL Profile to a Different Statement

July 28, 2009, 4:29 pm

One of the old tricks with Outlines was to switch hints between two statements. This allowed hints to be applied to a statement to influence the plan that the optimizer chose. The original statement (without the hints) could then be made to behave by swapping the Outlines. It was always a questionable approach in my mind. However, DBMS_SQLTUNE has a built-in procedure to import hints into a SQL Profile which makes it feel a little less risky. So here’s a quick little script to do the old “Outline Switcheroo Trick”, but with SQL Profiles. It’s based on some work done a few months back by myself and Randolf Geist. Here’s a couple of posts to look at for background info:

This iteration has a couple of new scripts:

create_sql_profile2.sql – creates a profile for one statement based on hints from another (wrapper for rg_profile_hints3.sql)
rg_sqlprof3.sql – modified version of Randolf’s original script, pulls hints from v$sql_plan
sql_profile_hints.sql – shows the hints in a SQL Profile for 10g

NOTE: I have posted an update to this approach here:

How to Attach a SQL Profile to a Different Statement – Take 2

You may want to skip the example below and refer to it instead (don’t miss the caveats at the bottom of this post though).

Here’s an example:

> sqlplus "/ as sysdba"

SQL*Plus: Release 10.2.0.3.0 - Production on Tue Jul 28 15:38:22 2009

Copyright (c) 1982, 2006, Oracle.  All Rights Reserved.


Connected to:
Oracle Database 10g Enterprise Edition Release 10.2.0.3.0 - Production
With the Partitioning, OLAP and Data Mining options

SQL> @flush_pool

System altered.

Elapsed: 00:00:00.31
SQL> set echo on
SQL> set timing on
SQL> @avgskewi
SQL> select avg(pk_col) from kso.skew
  2  where col1 = 23489
  3  /

AVG(PK_COL)
-----------


Elapsed: 00:00:00.01
SQL> @avgskewi_hint
SQL> select /*+ full(skew) */ avg(pk_col) from kso.skew
  2  where col1 = 23489
  3  /

AVG(PK_COL)
-----------


Elapsed: 00:00:11.23
SQL> set timing off
SQL> @find_sql
SQL> select sql_id, child_number, plan_hash_value plan_hash, executions execs,
  2  (elapsed_time/1000000)/decode(nvl(executions,0),0,1,executions) avg_etime,
  3  buffer_gets/decode(nvl(executions,0),0,1,executions) avg_lio,
  4  sql_text
  5  from v$sql s
  6  where upper(sql_text) like upper(nvl('&sql_text',sql_text))
  7  and sql_text not like '%from v$sql where sql_text like nvl(%'
  8  and sql_id like nvl('&sql_id',sql_id)
  9  order by 1, 2, 3
 10  /
Enter value for sql_text: %skew%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
7s0b9ygcrj77u      0 3723858078          1           .01          134 select avg(pk_col) from kso.skew where col1 = 23489
9r9wq9xqsw6mu      0  568322376          1         10.97      173,731 select /*+ full(skew) */ avg(pk_col) from kso.skew where col
                                                                      1 = 23489

SQL> @dplan
SQL> select * from table(dbms_xplan.display_cursor('&sql_id','&child_no','typical'))
  2  /
Enter value for sql_id: 7s0b9ygcrj77u
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  7s0b9ygcrj77u, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 23489

Plan hash value: 3723858078

------------------------------------------------------------------------------------------
| Id  | Operation                    | Name      | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |           |       |       |    53 (100)|          |
|   1 |  SORT AGGREGATE              |           |     1 |    11 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| SKEW      |    54 |   594 |    53   (2)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | SKEW_COL1 |    54 |       |     3   (0)| 00:00:01 |
------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=23489)


20 rows selected.

SQL> @dplan
SQL> select * from table(dbms_xplan.display_cursor('&sql_id','&child_no','typical'))
  2  /
Enter value for sql_id: 9r9wq9xqsw6mu
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  9r9wq9xqsw6mu, child number 0
-------------------------------------
select /*+ full(skew) */ avg(pk_col) from kso.skew where col1 = 23489

Plan hash value: 568322376

---------------------------------------------------------------------------
| Id  | Operation          | Name | Rows  | Bytes | Cost (%CPU)| Time     |
---------------------------------------------------------------------------
|   0 | SELECT STATEMENT   |      |       |       | 31719 (100)|          |
|   1 |  SORT AGGREGATE    |      |     1 |    11 |            |          |
|*  2 |   TABLE ACCESS FULL| SKEW |    54 |   594 | 31719  (37)| 00:00:43 |
---------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - filter("COL1"=23489)


19 rows selected.

SQL> -- so one statement hinted to use full table scan the other not hinted is using an index
SQL> -- let's try creating a profile from the hinted version and putting it on none hinted statement
SQL> set echo off
SQL> @create_sql_profile2
Enter value for sql_id to generate profile from: 9r9wq9xqsw6mu
Enter value for child_no to generate profile from: 0
Enter value for sql_id to attach profile to: 7s0b9ygcrj77u
Enter value for child_no to attach profile to: 0
Enter value for category:
Enter value for force_matching:

PL/SQL procedure successfully completed.

SQL> @sql_profiles
Enter value for sql_text: %skew%
Enter value for name:

NAME                           CATEGORY        STATUS   SQL_TEXT                                                               FOR
------------------------------ --------------- -------- ---------------------------------------------------------------------- ---
PROFILE_922pr090z0bvm          DEFAULT         ENABLED  select sql_id, dbms_lob.substr(sql_text,3999,1) sql_text from dba_hist NO
PROFILE_7s0b9ygcrj77u_attach   DEFAULT         ENABLED  select avg(pk_col) from kso.skew                                       NO

SQL> @sql_profile_hints
Enter value for profile_name: PROFILE_7s0b9ygcrj77u

HINT
------------------------------------------------------------------------------------------------------------------------------------------------------
IGNORE_OPTIM_EMBEDDED_HINTS
OPTIMIZER_FEATURES_ENABLE('10.2.0.3')
ALL_ROWS
OUTLINE_LEAF(@"SEL$1")
FULL(@"SEL$1" "SKEW"@"SEL$1")

SQL> @flush_pool

System altered.

SQL> @avgskewi

AVG(PK_COL)
-----------


SQL> @find_sql
Enter value for sql_text: %skew%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
7s0b9ygcrj77u      0  568322376          1         10.29      174,071 select avg(pk_col) from kso.skew where col1 = 23489

SQL> @dplan
Enter value for sql_id: 7s0b9ygcrj77u
Enter value for child_no:

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  7s0b9ygcrj77u, child number 0
-------------------------------------
select avg(pk_col) from kso.skew where col1 = 23489

Plan hash value: 568322376

---------------------------------------------------------------------------
| Id  | Operation          | Name | Rows  | Bytes | Cost (%CPU)| Time     |
---------------------------------------------------------------------------
|   0 | SELECT STATEMENT   |      |       |       | 31719 (100)|          |
|   1 |  SORT AGGREGATE    |      |     1 |    11 |            |          |
|*  2 |   TABLE ACCESS FULL| SKEW |    54 |   594 | 31719  (37)| 00:00:43 |
---------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - filter("COL1"=23489)

Note
-----
   - SQL profile "PROFILE_7s0b9ygcrj77u" used for this statement


23 rows selected.

SQL> -- so this worked, statement is now using a profile generated from hints on another statement

A couple of notes:

Beware of table aliases as they can cause hints to fail.
Beware of any structural changes as they can cause hints to fail.
Beware of the non-specific format of the INDEX hint.
(it leaves the optimizer with a lot of flexibility than you probably want it to have)
(for more details, see this post: Why Isn’t Oracle Using My Outline / Profile / Baseline?

Your comments are always welcomed.

Category: Oracle, Plan Stability, Tuning | 14 Comments

Oracle 11g Adaptive Cursor Sharing (ACS)

June 1, 2009, 9:57 am

Ah, the long awaited fix for the Bind Variable Peeking problem.

Adaptive Cursor Sharing (ACS) sounds great if you say it fast. Unfortunately it doesn’t work quite as well as I had hoped (at least as of 11.1.0.7). I was really hoping that we’d never have to worry about plan instability due to bind variable peeking again, but it seems that will remain an elusive goal for a while longer.

So the goal of this post is to provide some data about how ACS works based on observations of a couple of production systems. By the way, this post assumes you already have a basic understanding of how ACS works. There are some links at the bottom of this post to other references and in particular, this post is a good basic description of ACS.

So here’s some background info:
Observations were made on a version 10.2.0.4 RAC database that was being migrated to an 11.1.0.7 RAC database. Both are on Redhat Linux and similar Dell hardware. The version 10 database had several queries which suffered from bind variable peeking issues which were addressed with Outlines (while the developers considered using literals). Also, the statements were using real bind variables, not the fake kind that result from setting the cursor_sharing parameter. We were hoping that ACS would solve the bind variable peeking problem without manual intervention (i.e. without using Outlines or SQL Profiles or Baselines to lock in a specific plan).

I have used several scripts in this post:

unstable_plans.sql – this one shows statements that have multiple plans with large variance in execution time
awr_plan_change.sql – history of how the statement plan changes over time
awr_plan_stats.sql – aggregate statement stats (like elapsed_time, lio, etc) grouped by plan
find_sql_acs.sql – A queries v$sql and shows ACS related columns
mismatch3.sql – A variation of Dion Cho’s script to display data from v$sql_shared_cursor (see his post here)

The first couple of these scripts I discussed in a previous post on Plan Instability. I also did a previous post that is a basic overview of the Bind Variable Peeking issue, if you want a little more background info.

So here’s a look at what’s going on with that newly migrated system:

SQL*Plus: Release 11.1.0.7.0 - Production on Mon May 4 19:53:00 2009

Copyright (c) 1982, 2008, Oracle.  All rights reserved.


Connected to:
Oracle Database 11g Enterprise Edition Release 11.1.0.7.0 - 64bit Production
With the Partitioning, Real Application Clusters, OLAP, Data Mining
and Real Application Testing options

SQL> -- find statements with multiple plans with big differences in elapsed time
SQL>
SQL> @unstable_plans
Enter value for min_stddev:
Enter value for min_etime: 1

SQL_ID        SUM(EXECS)   MIN_ETIME   MAX_ETIME   NORM_STDDEV
------------- ---------- ----------- ----------- -------------
f2pz10qx59awc          2       11.75       45.31        2.0197
5mh2127hkzbtr         70        2.64       18.06        3.0272
0hur96bxr18jn         24        1.65        9.14        3.1981
76gduk3urk91d          6        9.75       57.82        3.4880
cqxkwk9hp8rpf         31        7.18       43.77        3.6015
3u2bxt4y0740a         17        0.49        4.19        4.1316
af6j2dyzawp7w         78        6.83       60.31        4.4492
2mzzy3u2rtgqx         93        4.55       34.13        4.6025
6vb3gxdfzbhuz         33        0.63        5.21        5.1502
gc69y3vv5ws31         72        0.87        7.64        5.5128
b6zcb86sub9gv          2        0.95        8.74        5.8349
6pdbja617d2g7          2        2.24       23.55        6.7132
cc7yv55yn2wzm          5        0.26        3.05        7.4533
ach69kkyac77x          5        0.23        2.65        7.5202
09xqs3yhmnnc2         82        0.31        4.47        7.5534
3zqwzanpnddt1          2        0.69        8.75        8.2026
70zr1cg7ssfkw          2        0.71        9.04        8.2487
664tcunn5nks9          3        0.36        4.83        8.7858
39f6bx40awrms          2        0.74       10.15        9.0125
5z7v0n6amf8yx        116        9.06      125.53        9.0942
3q67n6qh7tcqv          2        0.08        1.20        9.2843
30yrz0qst88mj         68        0.21        2.97        9.3903
a1mk6hw6s20an         19        0.26        3.78        9.6454
26070mzfxps8d         72        0.18        2.75       10.0027
byznf81kmwumv          2        0.75       11.45       10.0407
1fj1qcqtmgmd1          2        0.54        9.33       11.4092
fg96c4y95u3s8          2        0.49        9.18       12.6745
chxn6vwj02xj4          2        0.65       12.27       12.7001
2xg8psmr3k7vz          2        0.76       14.38       12.7429
grysxv4s2hhkb          2        0.63       12.10       12.8338
2bfs79h84xsch        148        5.65      108.87       12.9179
4qz01hjwat4u3         39        0.27        5.50       13.6528
3wj5ngbv1sa9x          2        0.40        8.70       14.7151
g68szg2ydq6dg         14        0.26        7.48       19.4587
9vt6aaf5xcmh2        381        0.67       24.90       19.9706
cs8ng5sv7jgj4          4        1.12       35.70       21.8969
12a2xbmwn5v6z          7        0.23        8.08       23.7235
d2x7g9wr30v33          4       12.45      638.60       25.4008
4ymph98r42nbj        192        0.11        4.43       26.9188
1uby0zcw55cnp          4        0.63       31.22       34.3088
4jhx8qrkzztqg         15        1.22       66.07       37.6215
7xu6y0cvs55gh         34        0.44       30.08       37.9640
6hstnb2fghg76         77        0.65       49.01       39.2329
gzwgbycgs0fx9        265        0.08        7.37       47.4965
f028rmkp3qjvq         47        0.03        1.99       48.5307
7s1nc9wa2pc4r          2        0.19       15.53       57.6592
f2tm6xrb26y51          2        0.17       14.80       61.7260
0xz1j5y313f3c        206        0.02        2.38       71.6444
3dhwvfmkjzwtv         72        1.24      154.56       87.6684
fb90nawgwx3mj         37        0.34       51.96      108.3873
b7d0d3gu5fvqp         22        0.13       33.85      137.5321
ghdy23pftj44q       1100        0.02        5.93      143.7765
7v2jtb3u02qx6         10        0.43      139.36      172.2951
fw9ntwzhygmcq         87        0.32      100.44      220.3149
gxv6umvct0xsv       4188        0.84      333.79      225.1338
6jdu11g4zzjkh         42        0.41      137.88      234.5440
2wrngntk7v0st        183        0.11       50.61      333.9597
27wha8b8s21xw       1112        0.01        7.08      408.3026
dhmvcrmgdk3sn        881        0.05       46.99      620.1920
6u4c54k36ngwf       4329        0.00        4.39      656.4506
8jt9yh7jf8tn8       4788        0.09      160.35    1,251.5684
4fy7uznh9zz27       4723        0.03       47.16    1,256.8971
2ddh1h012t8au         12        0.03       67.62    1,491.8099
fw9hrrv37hb3v          5        0.04      100.86    1,503.5361
68wg4gjb51dsh       4411        0.01       16.44    1,539.4726
7d407h5cqmv81       4202        0.00      180.63   28,768.6107

66 rows selected.

Please note that the unstable_plan.sql script is not guaranteed to find every statement that suffers from plan instability, because some of the good plans never make it into the AWR tables. This is due to the fact that AWR only grabs the “worst” statements in the various categories that AWR reports (i.e. elapsed time, cpu time, gets, reads, and executions). But you could argue that it will find the most important ones, because even when they run fast they still end up in the top of at least one category. Anyway, it’s obvious that there are many statements that are running with multiple plans with wide variances in their execution time.

So let’s look a little closer:

SQL> -- Let's check out the worst one on the list
SQL> --   first let's see how many plans have been used and how they stack up
SQL>
SQL> @awr_plan_stats
Enter value for sql_id: 7d407h5cqmv81
Enter value for snap_id:

SQL_ID        PLAN_HASH_VALUE        EXECS          ETIME    AVG_ETIME        AVG_LIO
------------- --------------- ------------ -------------- ------------ --------------
7d407h5cqmv81      4289789142          840            2.4        0.003          273.7
7d407h5cqmv81      1007536393          551          116.2        0.211       14,563.1
7d407h5cqmv81      1723168170        2,852       44,716.2       15.679      255,603.3
7d407h5cqmv81      2337118685            1          180.6      180.629    6,495,990.0

SQL> -- So the best plan was executed 840 times and took .003 seconds on average
SQL> -- The worst one was only executed once but took 180.6 seconds and did about 6.5M lios
SQL>
SQL>  -- Now let's see if it looks like bind variable peeking - (i.e. the plan is flip-flopping)
SQL>
SQL> @awr_plan_change
Enter value for sql_id: 7d407h5cqmv81

   SNAP_ID   NODE BEGIN_INTERVAL_TIME            SQL_ID        PLAN_HASH_VALUE        EXECS    AVG_ETIME        AVG_LIO
---------- ------ ------------------------------ ------------- --------------- ------------ ------------ --------------
      1732      2 22-APR-09 01.00.06.582 PM      7d407h5cqmv81      1007536393            1        1.478        5,269.0
      1733      2 22-APR-09 02.00.06.425 PM      7d407h5cqmv81                            8        1.635       14,580.0
      1734      2 22-APR-09 03.00.01.366 PM      7d407h5cqmv81                            6        0.196       14,580.0
      1734      3 22-APR-09 03.00.00.710 PM      7d407h5cqmv81      1723168170            2        8.891      228,740.5
      1735      2 22-APR-09 04.00.19.942 PM      7d407h5cqmv81      1007536393            3        0.189       14,580.0
      1736      2 22-APR-09 05.00.06.982 PM      7d407h5cqmv81                           63        0.188       14,580.0
      1736      3 22-APR-09 05.00.06.350 PM      7d407h5cqmv81      1723168170           22        9.564      236,902.3
      1737      2 22-APR-09 06.00.03.582 PM      7d407h5cqmv81      1007536393          244        0.187       14,580.0
      1737      3 22-APR-09 06.00.04.267 PM      7d407h5cqmv81      1723168170           76        9.505      236,959.9
      1738      2 22-APR-09 07.00.28.278 PM      7d407h5cqmv81      1007536393          226        0.188       14,580.0
      1738      3 22-APR-09 07.00.28.926 PM      7d407h5cqmv81      1723168170           71        9.395      240,745.0
      1739      2 22-APR-09 08.00.09.681 PM      7d407h5cqmv81                           81       11.114      253,481.2
      1739      3 22-APR-09 08.00.10.422 PM      7d407h5cqmv81                           22        9.866      249,882.3
      1740      2 22-APR-09 09.00.43.176 PM      7d407h5cqmv81                          215       13.682      256,467.0
      1740      3 22-APR-09 09.00.43.910 PM      7d407h5cqmv81                           80       12.605      252,606.0
      1741      2 22-APR-09 10.00.16.298 PM      7d407h5cqmv81                          367       20.209      256,157.1
      1741      3 22-APR-09 10.00.17.072 PM      7d407h5cqmv81                          214       15.039      257,287.3
      1742      2 22-APR-09 11.00.28.426 PM      7d407h5cqmv81                          376       17.855      257,066.5
      1742      3 22-APR-09 11.00.27.666 PM      7d407h5cqmv81                          178       13.437      255,902.4
      1743      2 23-APR-09 12.00.16.137 AM      7d407h5cqmv81                          352       18.639      257,326.6
      1743      3 23-APR-09 12.00.15.386 AM      7d407h5cqmv81                          182       13.787      258,192.2
      1744      2 23-APR-09 01.00.03.520 AM      7d407h5cqmv81                          285       16.275      256,335.3
      1744      3 23-APR-09 01.00.02.838 AM      7d407h5cqmv81                           94       13.492      258,508.9
      1745      2 23-APR-09 02.00.21.107 AM      7d407h5cqmv81                          132       14.876      258,913.5
      1745      3 23-APR-09 02.00.20.482 AM      7d407h5cqmv81                          103       13.113      256,821.0
      1750      2 23-APR-09 07.00.33.920 AM      7d407h5cqmv81      4289789142           77        0.002          267.0
      1753      2 23-APR-09 09.34.00.440 AM      7d407h5cqmv81                          278        0.001          267.0
      1754      2 23-APR-09 11.00.06.058 AM      7d407h5cqmv81                           96        0.001          267.0
      1754      3 23-APR-09 11.00.05.422 AM      7d407h5cqmv81                           42        0.000          267.0
      1755      2 23-APR-09 11.17.45.649 AM      7d407h5cqmv81                          283        0.001          267.0
      1756      2 23-APR-09 12.00.35.977 PM      7d407h5cqmv81                           62        0.000          267.0
      1894      3 29-APR-09 06.00.09.823 AM      7d407h5cqmv81                            1        0.444        2,777.0
      1900      2 29-APR-09 12.00.36.427 PM      7d407h5cqmv81      2337118685            1      180.629    6,495,990.0
      1943      3 01-MAY-09 07.00.02.507 AM      7d407h5cqmv81      4289789142            1        1.199        3,426.0

34 rows selected.

SQL> -- It does look like a typical bind variable peeking flip-flop pattern
SQL>
SQL> -- Now let's see if it's still in the shared pool and if it's bind aware
SQL>
SQL> @find_sql_acs
Enter value for sql_text:
Enter value for sql_id: 7d407h5cqmv81
Enter value for is_bind_aware:

SQL_ID         CHILD PLAN_HASH_VALUE IBS IBA ISH      EXECS ROWS_PROCESSED  AVG_ETIME    AVG_CPU    AVG_PIO    AVG_LIO SQL_TEXT
------------- ------ --------------- --- --- --- ---------- -------------- ---------- ---------- ---------- ---------- ------------------------------
7d407h5cqmv81      0      4289789142 N   N   Y            2              2       0.62       0.07     315.50      1,758 SELECT COUNT(*) as total_recor
7d407h5cqmv81      1      4289789142 N   N   Y            2              2       0.03       0.01       1.00        264

SQL> -- It is in the shared pool, but it is not bind aware
SQL>

So the previous example showed a statement that had several plans, one of which definitely had better performance characteristics. But since there was only one plan in the shared pool at the time we examined it, there is is no reason to expect that Oracle would have recognized that the statement should be bind aware. This brings up an interesting point. It does not appear that (at least as of 11.1.0.7) Oracle keeps track of bind sensitivity of a statement persistently. That is to say, if the statement gets flushed for any reason, the optimizer appears to completely forget about any analysis it has done up to that point. Thus the painful (for the user) process of discovering which sets of bind variables should go with which plan starts all over.

So here’s another statement:

SQL> -- another example from the list of unstable_plans
SQL>
SQL> @awr_plan_stats
Enter value for sql_id: 8jt9yh7jf8tn8

SQL_ID        PLAN_HASH_VALUE        EXECS          ETIME    AVG_ETIME        AVG_LIO
------------- --------------- ------------ -------------- ------------ --------------
8jt9yh7jf8tn8      1093407144        4,818          481.5        0.100        2,818.6
8jt9yh7jf8tn8      4076066623           21        3,269.3      155.679    5,901,988.0

SQL> @awr_plan_change
Enter value for sql_id: 8jt9yh7jf8tn8

   SNAP_ID   NODE BEGIN_INTERVAL_TIME            SQL_ID        PLAN_HASH_VALUE        EXECS    AVG_ETIME        AVG_LIO
---------- ------ ------------------------------ ------------- --------------- ------------ ------------ --------------
      1785      3 24-APR-09 05.00.13.361 PM      8jt9yh7jf8tn8      1093407144            6        1.102        2,872.7
      1786      2 24-APR-09 06.00.02.510 PM      8jt9yh7jf8tn8                          158        0.024        2,873.0
      1786      3 24-APR-09 06.00.03.170 PM      8jt9yh7jf8tn8                          223        0.023        2,873.0
      1787      2 24-APR-09 07.00.30.171 PM      8jt9yh7jf8tn8                          749        0.020        2,873.0
      1787      3 24-APR-09 07.00.30.935 PM      8jt9yh7jf8tn8                          873        0.019        2,873.0
      1788      2 24-APR-09 08.00.03.359 PM      8jt9yh7jf8tn8                          726        0.020        2,873.9
      1788      3 24-APR-09 08.00.04.148 PM      8jt9yh7jf8tn8                          871        0.020        2,873.9
      1789      2 24-APR-09 09.00.28.203 PM      8jt9yh7jf8tn8                          373        0.016        2,874.0
      1789      3 24-APR-09 09.00.27.481 PM      8jt9yh7jf8tn8                          566        0.016        2,874.0
      1892      2 29-APR-09 04.00.02.385 AM      8jt9yh7jf8tn8                            1        2.613        3,811.0
      1894      2 29-APR-09 06.00.09.154 AM      8jt9yh7jf8tn8                            2        0.462          733.0
      1894      3 29-APR-09 06.00.09.823 AM      8jt9yh7jf8tn8                            2        1.056          847.0
      1895      2 29-APR-09 07.00.00.226 AM      8jt9yh7jf8tn8                            7        1.714        2,869.6
      1895      3 29-APR-09 07.00.00.921 AM      8jt9yh7jf8tn8                            2        0.856        1,208.0
      1896      2 29-APR-09 08.00.20.446 AM      8jt9yh7jf8tn8                            9        1.635        2,103.0
      1897      2 29-APR-09 09.00.09.367 AM      8jt9yh7jf8tn8                            2        8.179        8,529.0
      1897      3 29-APR-09 09.00.10.115 AM      8jt9yh7jf8tn8                           17        1.714        3,416.5
      1898      2 29-APR-09 10.00.43.551 AM      8jt9yh7jf8tn8                            5        2.553        2,733.2
      1898      3 29-APR-09 10.00.42.788 AM      8jt9yh7jf8tn8                            6        3.751        4,484.2
      1899      3 29-APR-09 11.00.10.447 AM      8jt9yh7jf8tn8                            7        1.742        3,284.4
      1900      3 29-APR-09 12.00.35.788 PM      8jt9yh7jf8tn8                            2        1.199          966.0
      1901      2 29-APR-09 01.00.18.515 PM      8jt9yh7jf8tn8                            8        2.345        2,409.6
      1902      3 29-APR-09 02.00.15.910 PM      8jt9yh7jf8tn8                            2        3.941        2,649.5
      1905      2 29-APR-09 05.00.02.254 PM      8jt9yh7jf8tn8                            1        0.887        1,230.0
      1918      2 30-APR-09 06.00.09.089 AM      8jt9yh7jf8tn8                            1        0.653        1,248.0
      1918      3 30-APR-09 06.00.08.403 AM      8jt9yh7jf8tn8                            2        0.421          485.5
      1919      2 30-APR-09 07.00.28.148 AM      8jt9yh7jf8tn8                            1        1.152        1,242.0
      1920      2 30-APR-09 08.00.03.733 AM      8jt9yh7jf8tn8                            4        3.273        3,200.3
      1920      3 30-APR-09 08.00.04.389 AM      8jt9yh7jf8tn8                           12        2.491        3,314.2
      1921      2 30-APR-09 09.00.10.125 AM      8jt9yh7jf8tn8                            5        3.947        3,333.4
      1921      3 30-APR-09 09.00.10.838 AM      8jt9yh7jf8tn8                            2        2.416        1,769.5
      1922      3 30-APR-09 10.00.25.754 AM      8jt9yh7jf8tn8      4076066623            2       54.237    2,291,432.5
      1923      2 30-APR-09 11.00.17.345 AM      8jt9yh7jf8tn8      1093407144            2        0.812          975.0
      1923      3 30-APR-09 11.00.18.032 AM      8jt9yh7jf8tn8      4076066623            3      134.031      933,124.3
      1924      3 30-APR-09 12.00.15.448 PM      8jt9yh7jf8tn8                            3      227.009    6,987,169.3
      1926      2 30-APR-09 02.00.11.921 PM      8jt9yh7jf8tn8      1093407144            8        0.818        1,574.5
      1926      3 30-APR-09 02.00.11.174 PM      8jt9yh7jf8tn8      4076066623            2      175.709    8,963,417.0
      1927      2 30-APR-09 03.00.24.923 PM      8jt9yh7jf8tn8      1093407144            4        1.344        1,068.8
      1927      3 30-APR-09 03.00.24.306 PM      8jt9yh7jf8tn8      4076066623            5      156.378   10,159,992.0
      1928      2 30-APR-09 04.00.30.061 PM      8jt9yh7jf8tn8      1093407144            6        0.923        1,225.8
      1928      3 30-APR-09 04.00.29.416 PM      8jt9yh7jf8tn8      4076066623            1      180.488    2,150,190.0
      1930      3 30-APR-09 06.00.37.119 PM      8jt9yh7jf8tn8                            2      180.371    8,255,881.5
      1934      3 30-APR-09 10.00.12.055 PM      8jt9yh7jf8tn8                            1      180.491    3,102,577.0
      1939      2 01-MAY-09 03.00.31.764 AM      8jt9yh7jf8tn8      1093407144           21        0.825        1,041.8
      1939      3 01-MAY-09 03.00.32.453 AM      8jt9yh7jf8tn8                            4        0.575        1,211.8
      1944      3 01-MAY-09 08.00.15.686 AM      8jt9yh7jf8tn8                            6        1.328        1,788.3
      1946      2 01-MAY-09 10.00.17.105 AM      8jt9yh7jf8tn8                            1        1.170        2,411.0
      1946      3 01-MAY-09 10.00.16.458 AM      8jt9yh7jf8tn8                            4        2.041        2,414.3
      1947      3 01-MAY-09 11.00.14.385 AM      8jt9yh7jf8tn8                           10        1.725        2,937.1
      1948      3 01-MAY-09 12.00.08.928 PM      8jt9yh7jf8tn8                            3        2.232        3,415.7
      1987      2 03-MAY-09 03.00.03.550 AM      8jt9yh7jf8tn8                            7        1.029          901.0
      1990      3 03-MAY-09 06.00.07.641 AM      8jt9yh7jf8tn8                            3        1.225        1,465.7
      1991      3 03-MAY-09 07.00.05.445 AM      8jt9yh7jf8tn8                           26        0.370          710.5
      1992      2 03-MAY-09 08.00.20.010 AM      8jt9yh7jf8tn8                            6        0.213          685.7
      1992      3 03-MAY-09 08.00.19.366 AM      8jt9yh7jf8tn8                            3        0.658          883.0
      1993      2 03-MAY-09 09.00.04.983 AM      8jt9yh7jf8tn8                            8        0.769          950.9
      1996      2 03-MAY-09 12.00.19.205 PM      8jt9yh7jf8tn8                            2        0.101          861.5
      2015      3 04-MAY-09 07.00.13.869 AM      8jt9yh7jf8tn8                            4        0.376          854.5
      2016      3 04-MAY-09 08.00.09.477 AM      8jt9yh7jf8tn8                            6        0.143          571.0
      2019      2 04-MAY-09 11.00.11.317 AM      8jt9yh7jf8tn8                           12        0.937        1,352.1
      2019      3 04-MAY-09 11.00.10.691 AM      8jt9yh7jf8tn8                           10        1.612        1,341.9
      2019      3 04-MAY-09 11.00.10.691 AM      8jt9yh7jf8tn8      4076066623            1       41.592    3,942,672.0
      2020      2 04-MAY-09 12.00.06.355 PM      8jt9yh7jf8tn8      1093407144           15        1.037        1,734.6
      2020      3 04-MAY-09 12.00.06.919 PM      8jt9yh7jf8tn8      4076066623            1      181.044    1,764,007.0
      2022      2 04-MAY-09 02.00.26.599 PM      8jt9yh7jf8tn8      1093407144            2        2.214        2,780.5

65 rows selected.

SQL> -- typical bind variable peeking pattern
SQL> -- let's look at just one node - it'll be a little more clear
SQL> l8
  8* and ss.instance_number = S.instance_number
SQL> i
  9i and s.instance_number = &inst
 10i
SQL>
SQL> /
Enter value for sql_id: 8jt9yh7jf8tn8
Enter value for inst: 3

   SNAP_ID   NODE BEGIN_INTERVAL_TIME            SQL_ID        PLAN_HASH_VALUE        EXECS    AVG_ETIME        AVG_LIO
---------- ------ ------------------------------ ------------- --------------- ------------ ------------ --------------
      1785      3 24-APR-09 05.00.13.361 PM      8jt9yh7jf8tn8      1093407144            6        1.102        2,872.7
      1786      3 24-APR-09 06.00.03.170 PM      8jt9yh7jf8tn8                          223        0.023        2,873.0
      1787      3 24-APR-09 07.00.30.935 PM      8jt9yh7jf8tn8                          873        0.019        2,873.0
      1788      3 24-APR-09 08.00.04.148 PM      8jt9yh7jf8tn8                          871        0.020        2,873.9
      1789      3 24-APR-09 09.00.27.481 PM      8jt9yh7jf8tn8                          566        0.016        2,874.0
      1894      3 29-APR-09 06.00.09.823 AM      8jt9yh7jf8tn8                            2        1.056          847.0
      1895      3 29-APR-09 07.00.00.921 AM      8jt9yh7jf8tn8                            2        0.856        1,208.0
      1897      3 29-APR-09 09.00.10.115 AM      8jt9yh7jf8tn8                           17        1.714        3,416.5
      1898      3 29-APR-09 10.00.42.788 AM      8jt9yh7jf8tn8                            6        3.751        4,484.2
      1899      3 29-APR-09 11.00.10.447 AM      8jt9yh7jf8tn8                            7        1.742        3,284.4
      1900      3 29-APR-09 12.00.35.788 PM      8jt9yh7jf8tn8                            2        1.199          966.0
      1902      3 29-APR-09 02.00.15.910 PM      8jt9yh7jf8tn8                            2        3.941        2,649.5
      1918      3 30-APR-09 06.00.08.403 AM      8jt9yh7jf8tn8                            2        0.421          485.5
      1920      3 30-APR-09 08.00.04.389 AM      8jt9yh7jf8tn8                           12        2.491        3,314.2
      1921      3 30-APR-09 09.00.10.838 AM      8jt9yh7jf8tn8                            2        2.416        1,769.5
      1922      3 30-APR-09 10.00.25.754 AM      8jt9yh7jf8tn8      4076066623            2       54.237    2,291,432.5
      1923      3 30-APR-09 11.00.18.032 AM      8jt9yh7jf8tn8                            3      134.031      933,124.3
      1924      3 30-APR-09 12.00.15.448 PM      8jt9yh7jf8tn8                            3      227.009    6,987,169.3
      1926      3 30-APR-09 02.00.11.174 PM      8jt9yh7jf8tn8                            2      175.709    8,963,417.0
      1927      3 30-APR-09 03.00.24.306 PM      8jt9yh7jf8tn8                            5      156.378   10,159,992.0
      1928      3 30-APR-09 04.00.29.416 PM      8jt9yh7jf8tn8                            1      180.488    2,150,190.0
      1930      3 30-APR-09 06.00.37.119 PM      8jt9yh7jf8tn8                            2      180.371    8,255,881.5
      1934      3 30-APR-09 10.00.12.055 PM      8jt9yh7jf8tn8                            1      180.491    3,102,577.0
      1939      3 01-MAY-09 03.00.32.453 AM      8jt9yh7jf8tn8      1093407144            4        0.575        1,211.8
      1944      3 01-MAY-09 08.00.15.686 AM      8jt9yh7jf8tn8                            6        1.328        1,788.3
      1946      3 01-MAY-09 10.00.16.458 AM      8jt9yh7jf8tn8                            4        2.041        2,414.3
      1947      3 01-MAY-09 11.00.14.385 AM      8jt9yh7jf8tn8                           10        1.725        2,937.1
      1948      3 01-MAY-09 12.00.08.928 PM      8jt9yh7jf8tn8                            3        2.232        3,415.7
      1990      3 03-MAY-09 06.00.07.641 AM      8jt9yh7jf8tn8                            3        1.225        1,465.7
      1991      3 03-MAY-09 07.00.05.445 AM      8jt9yh7jf8tn8                           26        0.370          710.5
      1992      3 03-MAY-09 08.00.19.366 AM      8jt9yh7jf8tn8                            3        0.658          883.0
      2015      3 04-MAY-09 07.00.13.869 AM      8jt9yh7jf8tn8                            4        0.376          854.5
      2016      3 04-MAY-09 08.00.09.477 AM      8jt9yh7jf8tn8                            6        0.143          571.0
      2019      3 04-MAY-09 11.00.10.691 AM      8jt9yh7jf8tn8      4076066623            1       41.592    3,942,672.0
      2019      3 04-MAY-09 11.00.10.691 AM      8jt9yh7jf8tn8      1093407144           10        1.612        1,341.9
      2020      3 04-MAY-09 12.00.06.919 PM      8jt9yh7jf8tn8      4076066623            1      181.044    1,764,007.0
      2031      3 04-MAY-09 11.00.03.519 PM      8jt9yh7jf8tn8      1093407144            1        0.737          482.0
      2039      3 05-MAY-09 07.00.27.610 AM      8jt9yh7jf8tn8      4076066623            5       42.900    4,295,251.8
      2041      3 05-MAY-09 09.00.09.829 AM      8jt9yh7jf8tn8                            2        3.282    1,968,698.5
      2044      3 05-MAY-09 12.00.16.920 PM      8jt9yh7jf8tn8      1093407144            2        1.535          844.5
      2045      3 05-MAY-09 01.00.08.637 PM      8jt9yh7jf8tn8                            2        2.384        1,683.5

41 rows selected.

SQL> -- the plans are clearly flip-flopping
SQL> -- and the performance of plan 1093407144 is clearly orders of magnitude better
SQL>
SQL> -- Let's see what's in the shared pool
SQL>
SQL> @find_sql_acs
Enter value for sql_text:
Enter value for sql_id: 8jt9yh7jf8tn8
Enter value for is_bind_aware:

SQL_ID         CHILD PLAN_HASH_VALUE IBS IBA ISH      EXECS ROWS_PROCESSED  AVG_ETIME    AVG_CPU    AVG_PIO    AVG_LIO SQL_TEXT
------------- ------ --------------- --- --- --- ---------- -------------- ---------- ---------- ---------- ---------- -----------------------------------
8jt9yh7jf8tn8      0      4076066623 N   N   Y           19              6     160.35      29.28 ##########  6,222,898 SELECT row_order, cdr_id, site_id,
8jt9yh7jf8tn8      1      1093407144 N   N   Y           61              0       1.92       0.13     565.70      2,860 SELECT row_order, cdr_id, site_id,
8jt9yh7jf8tn8      2                 N   N   Y           55              0       1.01       0.06     252.09      1,555 SELECT row_order, cdr_id, site_id,

SQL> -- So there are children with both plans in the shared the pool (135 execs total)
SQL> -- But the cursors are not marked as bind aware
SQL> -- So why are there multiple child cursors?
SQL> -- (using a modified version of Dion Cho's script)
SQL>
SQL> @mismatch3
Enter value for sql_id: 8jt9yh7jf8tn8
SQL_ID                         = 8jt9yh7jf8tn8
CHILD_NUMBER                   = 1
--------------------------------------------------
SQL_ID                         = 8jt9yh7jf8tn8
CHILD_NUMBER                   = 0
ROLL_INVALID_MISMATCH          = Y
--------------------------------------------------
SQL_ID                         = 8jt9yh7jf8tn8
CHILD_NUMBER                   = 2
ROLL_INVALID_MISMATCH          = Y
--------------------------------------------------

PL/SQL procedure successfully completed.

SQL> -- none of the bind related flags show up, so it doesn't look promising for ACS
SQL> --

Brief Digression: The ROLL_INVALID_MISMATCH flag has to do with changing stats using AUTO_INVALIDATE which does not cause cursors to be immediately invalidated, but instead let’s them be invalidated over a rolling window (_optimizer_invalidation_period which defaults to 5 hours).

So then I got to wondering if any statements were being marked as bind aware.

SQL> @find_sql_acs
Enter value for sql_text:
Enter value for sql_id:
Enter value for is_bind_aware: Y

SQL_ID         CHILD PLAN_HASH_VALUE IBS IBA ISH      EXECS ROWS_PROCESSED  AVG_ETIME    AVG_CPU    AVG_PIO    AVG_LIO SQL_TEXT
------------- ------ --------------- --- --- --- ---------- -------------- ---------- ---------- ---------- ---------- ---------------
0qvgb3dyfg539      1       722236007 Y   Y   Y            2              0        .15        .02      23.00      3,487 SELECT row_orde
17uuqnvxmzxhj      1      3038781757 Y   Y   Y           31             31        .17        .01      43.74      1,126 SELECT COUNT(*)
                   3      3038781757 Y   Y   N           21             21        .02        .02       1.33      7,290
                   4      3038781757 Y   Y   Y           52             52        .23        .02     120.29      2,046
                   6      3038781757 Y   Y   Y           51             51        .00        .00        .10        284
34x6683rpwtxa      4       722236007 Y   Y   Y           18            164        .01        .00        .17        498 SELECT row_orde
3tfx8fzp64vkb      1      3038781757 Y   Y   Y            2              2        .01        .01        .00      1,178 SELECT COUNT(*)
4vb86f36xqc50      1      2983410489 Y   Y   Y           62           1683        .12        .01      53.76        960 SELECT row_orde
                   4      2983410489 Y   Y   Y            7            163        .69        .07     328.43        723
58p0j1q6rmv34      1      1144901783 Y   Y   Y            2              2        .02        .00        .00        335 SELECT COUNT(*)
5mxqphz5qfs4d      1      1144901783 Y   Y   Y            2              2        .02        .00        .00         54 SELECT COUNT(*)
dt1v1cmua9cnq      1      4076066623 Y   Y   Y            8             37       3.47       3.41      15.63  2,233,144 SELECT row_orde
ftxa99d89yzz0      1      4289789142 Y   Y   Y            2              2        .01        .00        .00        157 SELECT COUNT(*)
g375mcpc30dy5      2      1690109023 Y   Y   N            1             10        .03        .01        .00        767 SELECT row_orde
                   3      1690109023 Y   Y   Y            5             24        .02        .00       2.00        362

15 rows selected.

SQL> --

Sure enough, there are a few (10 statements to be exact with a total of 15 child cursors) that are marked as Bind Aware. However, there are only 3 statements that have multiple child cursors (sql_id: 17uuqnvxmzxhj, 4vb86f36xqc50, g375mcpc30dy5). And for each of those statements, the child cursors all have the same plan (sql_id: 17uuqnvxmzxhj, for example, has 3 children all using plan_hash_value: 3038781757). So even though they are marked Bind Aware, and have multiple child cursors, they are not producing distinct plans for those statements. So even the ones that the optimizer has noticed, do not appear to be providing us any benefit.

But back to the original question. We have many statements that are suffering from bind variable peeking issues that are apparently not being noticed. Why is that? Well I got to thinking about why ACS might be ignoring the statements that I know have this issue. One of the characteristics of these statements is that they have a relatively large number of bind variables. Some of them have as many as a couple of hundred. So I let my mind wander off into programmer land. How would the guys writing the optimizer code deal with a situation where they had a virtually unlimited number of bind variables. My first thought was to just put a hard limit on the number of variables to handle. Histograms have a relatively small number of potential buckets, and since ACS uses a histogram approach, it stands to reason the programmers might have put in a relatively small limit for their first pass. So I went off to test this idea (since this post is already so long I’ll cut right to the chase). There does appear to be a hard limit of 14 bind variables and statements that have more than that are apparently not evaluated for bind sensitivity. Here’s a test case:

> !sql
sqlplus "/ as sysdba"

SQL*Plus: Release 11.1.0.7.0 - Production on Mon May 11 11:16:06 2009

Copyright (c) 1982, 2008, Oracle.  All rights reserved.


Connected to:
Oracle Database 11g Enterprise Edition Release 11.1.0.7.0 - Production
With the Partitioning, OLAP, Data Mining and Real Application Testing options

SQL> !cat t14.sql
set echo off
variable v1 number
variable v2 varchar2(30)
variable v3 varchar2(30)
variable v4 varchar2(30)
variable v5 varchar2(30)
variable v6 varchar2(30)
variable v7 varchar2(30)
variable v8 varchar2(30)
variable v9 varchar2(30)
variable v9 varchar2(30)
variable v10 varchar2(30)
variable v11 varchar2(30)
variable v12 varchar2(30)
variable v13 varchar2(30)
variable v14 varchar2(30)
variable v15 varchar2(30)
variable v16 varchar2(30)
variable v17 varchar2(30)
variable v18 varchar2(30)
variable v19 varchar2(30)
exec :v1 := 999999;
exec :v2 := 'TESTING'
exec :v3 := '01-jan-08'
exec :v4 := '01-jan-09'
exec :v5 := 'Y'
exec :v6 := 'X'
exec :v7 := 'y'
exec :v8 := 'Z'
exec :v9 := 'a'
exec :v10 := 'b'
exec :v10 := 'c'
exec :v11 := 'd'
exec :v12 := 'e'
exec :v13 := 'f'
exec :v14 := 'g'
exec :v15 := 'h'
exec :v16 := 'i'
exec :v17 := 'j'
exec :v18 := 'k'
exec :v19 := 'l'
set echo on
select avg(pk_col) from kso.little_skew
where col1 = :v1
and col2 = :v2
and col3 between :v3 and :v4
and col4 in (:v5,:v6,:v7,:v8,:v9,:v10,:v11,:v12,:v13,:v14)
/

SQL> @flush_pool
SQL> @t14
SQL> @t14
SQL> @t14
SQL> @t14
SQL>
SQL> -- 4 execs of the first bind variable set, now let's use a different set of bind variables
SQL> -- t14a.sql is the same except v1=1 - which (due to histogram) wants to use a different plan
SQL>
SQL> @t14a
SQL> @t14a
SQL> @t14a
SQL> @t14a
SQL> @t14a
SQL> @t14a
SQL> @t14a
SQL>
SQL> -- 7 execs with the new set of bind variables, should give it plenty of info to make it bind aware
SQL> -- now a few more with the original set of bind variables
SQL>
SQL> @t14
SQL> @t14
SQL> @t14
SQL> @t14
SQL>
SQL> -- now let's see what we've got
SQL>
SQL> @find_sql_acs
Enter value for sql_text: %v14)%
Enter value for sql_id:
Enter value for is_bind_aware:

SQL_ID         CHILD PLAN_HASH_VALUE IBS IBA ISH      EXECS ROWS_PROCESSED  AVG_ETIME    AVG_CPU    AVG_PIO    AVG_LIO SQL_TEXT
------------- ------ --------------- --- --- --- ---------- -------------- ---------- ---------- ---------- ---------- -----------------------------------
2yk8hbkc4kbd5      0       376960484 N   N   N            8              8        .18        .18        .00      2,641 select avg(pk_col) from kso.little_
                                                                                                                       skew where col1 = :v1 and col2 = :v
                                                                                                                       2 and col3 between :v3 and :v4 and
                                                                                                                       col4 in (:v5,:v6,:v7,:v8,:v9,:v10,:
                                                                                                                       v11,:v12,:v13,:v14)

2yk8hbkc4kbd5      1      3746388338 N   Y   Y            3              3        .00        .00        .00         15 select avg(pk_col) from kso.little_
                                                                                                                       skew where col1 = :v1 and col2 = :v
                                                                                                                       2 and col3 between :v3 and :v4 and
                                                                                                                       col4 in (:v5,:v6,:v7,:v8,:v9,:v10,:
                                                                                                                       v11,:v12,:v13,:v14)

2yk8hbkc4kbd5      2       376960484 N   Y   Y            4              4        .00        .00        .00          3 select avg(pk_col) from kso.little_
                                                                                                                       skew where col1 = :v1 and col2 = :v
                                                                                                                       2 and col3 between :v3 and :v4 and
                                                                                                                       col4 in (:v5,:v6,:v7,:v8,:v9,:v10,:
                                                                                                                       v11,:v12,:v13,:v14)


3 rows selected.

SQL> -- As expected, the optimizer has noticed and marked it Bind Aware
SQL> -- Now let's try the same thing with 15 bind variables instead of 14
SQL> -- (note: t15 is the same with one more bind variable)
SQL>
SQL> @t15
SQL> @t15
SQL> @t15
SQL> @t15
SQL> @t15a
SQL> @t15a
SQL> @t15a
SQL> @t15a
SQL> @t15a
SQL> @t15a
SQL> @t15a
SQL> @t15
SQL> @t15
SQL> @t15
SQL> @t15
SQL> @find_sql_acs
Enter value for sql_text: %v15)%
Enter value for sql_id:
Enter value for is_bind_aware:

SQL_ID         CHILD PLAN_HASH_VALUE IOB IBA ISH      EXECS ROWS_PROCESSED  AVG_ETIME    AVG_CPU    AVG_PIO    AVG_LIO SQL_TEXT
------------- ------ --------------- --- --- --- ---------- -------------- ---------- ---------- ---------- ---------- -----------------------------------
4ndg8w1ga5dth      0       376960484 N   N   Y           15             15        .17        .16        .00      2,465 select avg(pk_col) from kso.little_
                                                                                                                       skew where col1 = :v1 and col2 = :v
                                                                                                                       2 and col3 between :v3 and :v4 and
                                                                                                                       col4 in (:v5,:v6,:v7,:v8,:v9,:v10,:
                                                                                                                       v11,:v12,:v13,:v14,:v15)


1 row selected.

SQL> -- no joy!
SQL>
SQL> -- so now I wondered if it really was just a hard limit or something more complicated
SQL> -- so I wrote a little script to count the number of bind variables in Bind Aware statements
SQL>
SQL> !cat acs_bind_count.sql
select distinct sql_id, bind_count from (
select sql_id, child_number, count(*) bind_count from v$sql_bind_capture
where sql_id in (
select sql_id from v$sqlarea where is_bind_aware = 'Y')
group by sql_id, child_number
)
order by bind_count
/

SQL> @acs_bind_count.sql

SQL_ID        BIND_COUNT
------------- ----------
2jmg3n6k2q82x          2
dxjvgtd3stafn          4
ck67mwdmdnaww          8
9pcw6qh83mj69          9
883uvnn2gz36u         10
4ysyd47nkap6d         11
7mygfqgs52au2         12
2744r65xx9h2h         13
2yk8hbkc4kbd5         14

9 rows selected.

So it looks like there probably is a hard limit. Let’s see if I can disprove that by looking at a couple of production systems. Here’s the output from the same script on four production instances (note: system 1 is that same one that I referenced earlier with the statements with known Bind Variable Peeking issues, where ACS was not noticing them):

-- System 1, Node 2

SQL> @acs_bind_count

SQL_ID        BIND_COUNT
------------- ----------
17uuqnvxmzxhj          8
58p0j1q6rmv34          8
5mxqphz5qfs4d          8
g375mcpc30dy5          8
3tfx8fzp64vkb          9
4vb86f36xqc50          9
34x6683rpwtxa         10
dt1v1cmua9cnq         11
ftxa99d89yzz0         11
0qvgb3dyfg539         12

10 rows selected.


-- System 1, Node 3

SQL> @acs_bind_count

SQL_ID        BIND_COUNT
------------- ----------
5bjg6w9btv3zn          7
17uuqnvxmzxhj          8
6n1790gk5m0hy          8
2pv7g3nutnyq5          9
4vb86f36xqc50          9
11at9nnhrw3w9         10
4p9zp29bcu927         10
4axts2hm73n98         11
ftxa99d89yzz0         11
490gh9uugyqqq         13

10 rows selected.

-- System 2, Node 1

SQL> @acs_bind_count

SQL_ID        BIND_COUNT
------------- ----------
4rqy85b9r413x          1
7h47mb48s19t3          1
51z6b0kbduf8m          2
djkchp3qwadu1          2
9g5ng8xjj4h05          3
amyvvzzjccvsg          3
cuv2pyzvz7b4z          3
d68jnfnqs6uh7          3
dkc2kbj7kdsu7          3
fxmfhkkhcrdj6          3
6196v5td8pk4n          4
9m63xcj6sbswu          4
0mn3xx02ww6pd          5
c7k3pwbjg4d1d          5
dy98ajwqc8s2x          5
3qh6yw37n8m1a          6
3xxgg248shg62          6
83v17f53rnzcv          6
a2271k4f7j211          6
06n7rk2jw3rsy          7
f4xr9x5wh46zt          7
48ryzfg5dxpqn          8
an9114vtxukz2          8

23 rows selected.

-- System 2, Node 2

SQL> @acs_bind_count

SQL_ID        BIND_COUNT
------------- ----------
4rqy85b9r413x          1
7h47mb48s19t3          1
gvj749s4654hm          1
51z6b0kbduf8m          2
6qwznvjfajh7t          2
djkchp3qwadu1          2
2mhfdtyrvhz3c          3
92a7wu0891bjk          3
9g5ng8xjj4h05          3
9p9gsakw5qyrg          3
amyvvzzjccvsg          3
bs63sfxynwtc6          3
cuv2pyzvz7b4z          3
d68jnfnqs6uh7          3
dvh3d8g2f844j          3
0341h5ytqbv7k          4
...
gj0rzh6xw2msp          4
grvh9mmkynm4u          4
0mn3xx02ww6pd          5
7ys2u732cj1ag          5
9kfj6kj32p7ku          5
dy98ajwqc8s2x          5
83v17f53rnzcv          6
d79xsp0utuvm2          6
gqkx5bsg1zfzc          6
4q3n2wwqtghma          7
f4xr9x5wh46zt          7
g7c90sr77bb78          7
7gb24h57r0spb          8
9zcy2yz537z41          8
an9114vtxukz2          8
7uwy0uxauuabz          9
80xmux45pvkrr          9

73 rows selected.

So it appears that there probably is a hard limit and that it probably is 14 (although there certainly could be a more complicated algorithm in play). None of the 4 production systems I checked had a single statement that was marked bind aware with more than 14 bind variables.

So here are a few closing thoughts:

To me, ACS doesn’t seem to be completely cooked yet. In fact, it seems to be somewhat of a futile attempt, since in the very best case, one execution with a bad plan would be necessary for the optimizer to recognize that a bind variable peeking issue existed. This wouldn’t be so bad if the information was persisted, so that the same “learning” process wouldn’t have to be endured if/when a statement gets flushed from the shared pool. This issue alone is enough to keep this feature from being relied upon in situations where performance is critical. In my opinion, the best approach remains unchanged from version 10, that being the judicious use of literals where necessary to prevent plan instability due to bind variable peeking.

My impression of it is not completely negative though. It’s certainly better than the old approach of pick a plan and stick with it. And for systems that use a limited number of binds per statement where performance swings are not as dramatic and/or performance is not as critical, it seems to work pretty well.

Here are some other references:

OptimizerMagic Blog – Good basic description of ACS
OptimizerMagic Blog – Update on ACS
Ric Van Dyke – Intelligent Cusor Sharing in 11.1.0.6
Ric Van Dyke – Intelligent Cusor Sharing in 11.1.0.7
Section on ACS in Troubleshooting Oracle Performance By Christian Antognini

Category: Oracle, Plan Stability | 18 Comments

Oracle 11g SQL Plan Management – SQL Plan Baselines

April 29, 2009, 3:17 pm

Note, this post applies to 11gR1 (specifically 11.1.0.7).

11g has a new method of dealing with plan instability (i.e. the tendency of a statement to flip flop between plans). The goal has always been to provide the best performance, but until 11g there has not been a mechanism that had as a design goal, the idea of eliminating backwards movement (“performance regressions” as the Oracle documentation calls them). That is, not allowing a statement to switch to a plan that is significantly slower than the one it has already been executing. This new mechanism depends on a construct called a Baseline. So for this post I am not going to focus on the process of evolving plans to prevent “performance regressions”, but rather on the Baselines themselves. (hopefully I’ll get to the plan management part soon)

Here’s a little excerpt from the 11gR1 documentation:

Each time a SQL statement is compiled, the optimizer first uses a cost-based search method to build a best-cost plan, then tries to find a matching plan in the SQL plan baseline. If a match is found, the optimizer will proceed using this plan. Otherwise, it evaluates the cost of each accepted plan in the SQL plan baseline and selects the plan with the lowest cost. The best-cost plan found by the optimizer that does not match any plans in the plan history for the SQL statement represents a new plan, and is added as a non-accepted plan to the plan history. The new plan is not used until it is verified to not cause a performance regression. However, if a change in the system (such as a dropped index) causes all accepted plans to become non-reproducible, the optimizer will select the best-cost plan. Thus, the presence of a SQL plan baseline causes the optimizer to use conservative plan selection strategy for the SQL statement.

Clear as mud?

Now my description:

Baselines are the latest evolution in Oracle’s efforts to allow a plan to be locked. The previous efforts were Outlines and SQL Profiles. Both of those efforts were based on the idea that hints could be applied to limit the optimizers choices down to one. That approach seems a little flawed. Why not just save the plan and be done with it? I believe that’s what Baselines are intended to do. Unfortunately, they don’t appear to do it yet. But they do have an advantage over Outlines and SQL Profiles in that they at least save the plan_hash_value, so they know if they are reproducing the correct plan or not. (see my previous post, Do Baselines Use Hints? – Take 2) And hopefully, they will evolve to the point where the actual plan is saved along with the hash value – we’ll see.

So anyway, here’s some basic housekeeping stuff on Baselines:

Baselines will be used by default in 11gR1, if they exist. There is a parameter to control whether they are used or not (OPTIMIZER_USE_SQL_PLAN_BASELINE). It is set to TRUE by default.
Baselines will not be created by default in 11gR1. So, much like with the older Outlines or SQL Profiles, you must do something to create them.
There is a view called DBA_SQL_PLAN_BASELINES that exposes the Baselines that have been created.
Just like Outlines and SQL Profiles, Baselines apply to all instances in a RAC environment (they are not localized to a specific instance).

Baselines can be created a couple of different ways. They can be created automatically by the database as it’s running by setting the OPTIMIZER_CAPTURE_SQL_PLAN_BASELINES parameter. They can also be created for statements in a SQL Tuning Set. But I’m not going to talk about either one of those approaches in this post, as I don’t think they really make much sense in the case where you want to use a Baseline to lock a plan for a specific statement. Instead, I am going to discuss creating a baseline for a statement that is in the shared pool via the DBMS_SPM.LOAD_PLANS_FROM_CURSOR_CACHE function.

All the function needs is a SQL_ID and a PLAN_HASH_VALUE. Optionally a parameter can be used to define the baseline as FIXED. If it’s FIXED then it gets priority over any other Baselines for that statement, except other FIXED Baselines. Confused? Well it’s not exactly the most straight forward setup. I’m kind of a simple guy, so at this point I’m thinking one FIXED Baseline is enough.

Before you get too bored, here’s a quick example:

SQL> select avg(pk_col) from kso.little_skew where col1 = 99320;

AVG(PK_COL)
-----------
     628922

SQL> @find_sql
Enter value for sql_text: %little%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
4dd2qjxbjav6u      0 2709260180          1           .02           89 select avg(pk_col) from kso.little_skew where col1 = 99320

SQL> @dplan
Enter value for sql_id: 4dd2qjxbjav6u
Enter value for child_no: 0

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  4dd2qjxbjav6u, child number 0
-------------------------------------
select avg(pk_col) from kso.little_skew where col1 = 99320

Plan hash value: 2709260180

-------------------------------------------------------------------------------------------------
| Id  | Operation                    | Name             | Rows  | Bytes | Cost (%CPU)| Time     |
-------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |                  |       |       |     4 (100)|          |
|   1 |  SORT AGGREGATE              |                  |     1 |     9 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| LITTLE_SKEW      |     1 |     9 |     4   (0)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | LITTLE_SKEW_COL1 |     1 |       |     3   (0)| 00:00:01 |
-------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=99320)

20 rows selected.

SQL> !cat create_baseline.sql
var ret number
exec :ret := dbms_spm.load_plans_from_cursor_cache(-
    sql_id=>'&sql_id', -
    plan_hashvalue=>&plan_hash_value,-
    fixed=>'&fixed');

SQL> @create_baseline
Enter value for sql_id: 4dd2qjxbjav6u
Enter value for plan_hash_value: 2709260180
Enter value for fixed: NO

PL/SQL procedure successfully completed.

SQL> !cat baselines.sql
set lines 155
col sql_text for a50 trunc
col last_executed for a28
col enabled for a7
col plan_hash_value for a16
col last_executed for a16
select spb.sql_handle, spb.plan_name, spb.sql_text,
spb.enabled, spb.accepted, spb.fixed,
to_char(spb.last_executed,'dd-mon-yy HH24:MI') last_executed
from
dba_sql_plan_baselines spb
where spb.sql_text like nvl('%'||'&sql_text'||'%',spb.sql_text)
and spb.sql_handle like nvl('&name',spb.sql_handle)
and spb.plan_name like nvl('&plan_name',spb.plan_name)
/

SQL> @baselines
Enter value for sql_text: %little%
Enter value for name:
Enter value for plan_name:

SQL_HANDLE                     PLAN_NAME                      SQL_TEXT                                           ENABLED ACC FIX LAST_EXECUTED
------------------------------ ------------------------------ -------------------------------------------------- ------- --- --- ----------------
SYS_SQL_b77256b604589dec       SYS_SQL_PLAN_04589dec2fdfd157  select avg(pk_col) from kso.little_skew where col1 YES     YES NO

SQL> select avg(pk_col) from kso.little_skew where col1 = 99320;

AVG(PK_COL)
-----------
     628922

SQL> select avg(pk_col) from kso.little_skew where col1 = 99320;

AVG(PK_COL)
-----------
     628922

SQL> @find_sql
Enter value for sql_text:
Enter value for sql_id: 4dd2qjxbjav6u

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
4dd2qjxbjav6u      0 2709260180          1           .02           89 select avg(pk_col) from kso.little_skew where col1 = 99320
4dd2qjxbjav6u      1 2709260180          1           .00            5 select avg(pk_col) from kso.little_skew where col1 = 99320

SQL> @dplan
Enter value for sql_id: 4dd2qjxbjav6u
Enter value for child_no: 1

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  4dd2qjxbjav6u, child number 1
-------------------------------------
select avg(pk_col) from kso.little_skew where col1 = 99320

Plan hash value: 2709260180

-------------------------------------------------------------------------------------------------
| Id  | Operation                    | Name             | Rows  | Bytes | Cost (%CPU)| Time     |
-------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |                  |       |       |     4 (100)|          |
|   1 |  SORT AGGREGATE              |                  |     1 |     9 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| LITTLE_SKEW      |     1 |     9 |     4   (0)| 00:00:01 |
|*  3 |    INDEX RANGE SCAN          | LITTLE_SKEW_COL1 |     1 |       |     3   (0)| 00:00:01 |
-------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=99320)

Note
-----
   - SQL plan baseline SYS_SQL_PLAN_04589dec2fdfd157 used for this statement

24 rows selected.

So that’s a quick example of how easy it is to create a Baseline. Once a Baseline is created it behaves much like an Outline or SQL Profile, in that it will be applied to any SQL statement where the normalized text matches. It’s interesting to note that even though Outlines are way outdated in 11g, they still take precedence over Baselines. So if you have an Outline and a Baseline on the same statement, the Outline will be used. Here’s an example of that behavior:
Continue reading ‘Oracle 11g SQL Plan Management – SQL Plan Baselines’ »

Category: Oracle, Plan Stability, Tuning | 53 Comments

Do SQL Plan Baselines Use Hints? – Take 2

April 23, 2009, 10:33 am

Warning – This post is almost pure speculation!

You may have read a previous post where I said I thought Baselines didn’t use hints. We’ll I’ve changed my mind. I no longer think that Baselines store an actual plan for a SQL statement. (See my previous post – Do SQL Plan Baselines Use Hints?) I never could find a place where the plan data was stored (only the plan_hash_value). So I had a closer look at some more 10053 trace files. Here’s a quick run down of what I found. First the set up:

SQL> @flush_pool

System altered.

SQL> select avg(pk_col) from kso.little_skew where col1 = 1;

AVG(PK_COL)
-----------
 310999.357

SQL> @find_sql
Enter value for sql_text: %little%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
9df852xw86wxt      0 3498336203          1           .18        3,437 select avg(pk_col) from kso.little_skew where col1 = 1

SQL> @dplan
Enter value for sql_id: 9df852xw86wxt
Enter value for child_no: 0

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  9df852xw86wxt, child number 0
-------------------------------------
select avg(pk_col) from kso.little_skew where col1 = 1

Plan hash value: 3498336203

----------------------------------------------------------------------------------
| Id  | Operation          | Name        | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------
|   0 | SELECT STATEMENT   |             |       |       |   907 (100)|          |
|   1 |  SORT AGGREGATE    |             |     1 |     9 |            |          |
|*  2 |   TABLE ACCESS FULL| LITTLE_SKEW |   620K|  5449K|   907   (2)| 00:00:11 |
----------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - filter("COL1"=1)


19 rows selected.

SQL> select /*+ index (a little_skew_col1) */ avg(pk_col) from kso.little_skew a where col1 = 1;

AVG(PK_COL)
-----------
 310999.357

SQL> @find_sql
Enter value for sql_text: %little%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
9df852xw86wxt      0 3498336203          1           .18        3,437 select avg(pk_col) from kso.little_skew where col1 = 1
fbnx1bws6n4xu      0 2709260180          1           .86        5,278 select /*+ index (a little_skew_col1) */ avg(pk_col) from ks
                                                                      o.little_skew a where col1 = 1


SQL> @dplan
Enter value for sql_id: fbnx1bws6n4xu
Enter value for child_no: 0

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  fbnx1bws6n4xu, child number 0
-------------------------------------
select /*+ index (a little_skew_col1) */ avg(pk_col) from
kso.little_skew a where col1 = 1

Plan hash value: 2709260180

-------------------------------------------------------------------------------------------------
| Id  | Operation                    | Name             | Rows  | Bytes | Cost (%CPU)| Time     |
-------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT             |                  |       |       | 20835 (100)|          |
|   1 |  SORT AGGREGATE              |                  |     1 |     9 |            |          |
|   2 |   TABLE ACCESS BY INDEX ROWID| LITTLE_SKEW      |   620K|  5449K| 20835   (1)| 00:04:11 |
|*  3 |    INDEX RANGE SCAN          | LITTLE_SKEW_COL1 |   620K|       |  3213   (1)| 00:00:39 |
-------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - access("COL1"=1)


21 rows selected.

SQL> -- need to create baseline for original statement to get SQL_HANDLE
SQL>
SQL> !cat create_baseline.sql
var ret number
exec :ret := dbms_spm.load_plans_from_cursor_cache(-
    sql_id=>'&sql_id', -
    plan_hash_value=>&plan_hash_value,-
    fixed=>'&fixed');




SQL> @create_baseline
Enter value for sql_id: 9df852xw86wxt
Enter value for plan_hash_value: 3498336203
Enter value for fixed: NO

PL/SQL procedure successfully completed.

SQL> -- now add the other plan as a fixed Baseline
SQL>
SQL> !cat create_baseline2.sql
var ret number
exec :ret := dbms_spm.load_plans_from_cursor_cache(-
    sql_id=>'&sql_id', -
    plan_hash_value=>&plan_hash_value,-
    sql_handle=>'&sql_handle',-
    fixed=>'&fixed');


SQL> @create_baseline2
Enter value for sql_id: fbnx1bws6n4xu
Enter value for plan_hash_value: 2709260180
Enter value for sql_handle: SYS_SQL_19fcc3effcce06c0
Enter value for fixed: YES

PL/SQL procedure successfully completed.

SQL> @baselines
Enter value for sql_text:
Enter value for name:
Enter value for plan_name:

SQL_HANDLE                     PLAN_NAME                      SQL_TEXT                                           ENABLED ACC FIX LAST_EXECUTED
------------------------------ ------------------------------ -------------------------------------------------- ------- --- --- ----------------
SYS_SQL_19fcc3effcce06c0       SYS_SQL_PLAN_fcce06c08b1420d2  select avg(pk_col) from kso.little_skew where col1 YES     YES NO
SYS_SQL_19fcc3effcce06c0       SYS_SQL_PLAN_fcce06c02fdfd157  select avg(pk_col) from kso.little_skew where col1 YES     YES YES

SQL> select avg(pk_col) from kso.little_skew where col1 = 1;

AVG(PK_COL)
-----------
 310999.357

SQL> /

AVG(PK_COL)
-----------
 310999.357

SQL> -- check to see if it's using the fixed Baseline
SQL> @find_sql
Enter value for sql_text: %little%
Enter value for sql_id:

SQL_ID         CHILD  PLAN_HASH      EXECS     AVG_ETIME      AVG_LIO SQL_TEXT
------------- ------ ---------- ---------- ------------- ------------ ------------------------------------------------------------
9df852xw86wxt      0 3498336203          2           .19        3,279 select avg(pk_col) from kso.little_skew where col1 = 1
fbnx1bws6n4xu      0 2709260180          1           .86        5,278 select /*+ index (a little_skew_col1) */ avg(pk_col) from ks
                                                                      o.little_skew a where col1 = 1


SQL>
SQL> @dplan
Enter value for sql_id: 9df852xw86wxt
Enter value for child_no: 0

PLAN_TABLE_OUTPUT
------------------------------------------------------------------------------------------------------------------------------------------------------
SQL_ID  9df852xw86wxt, child number 0
-------------------------------------
select avg(pk_col) from kso.little_skew where col1 = 1

Plan hash value: 3498336203

----------------------------------------------------------------------------------
| Id  | Operation          | Name        | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------
|   0 | SELECT STATEMENT   |             |       |       |   907 (100)|          |
|   1 |  SORT AGGREGATE    |             |     1 |     9 |            |          |
|*  2 |   TABLE ACCESS FULL| LITTLE_SKEW |   620K|  5449K|   907   (2)| 00:00:11 |
----------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - filter("COL1"=1)


19 rows selected.

SQL> -- no it's not using the Baseline, why not?

So we created a Fixed Baseline on a statement that used a hint to force an index based access path, attached it to another statement with no hints, and then re-ran the un-hinted statement. It did not pick up the Fixed Baseline. The next step was to have a look at a 10053 trace file. Here are some excerpts from the 10053 trace file.


...

SPM: statement found in SMB

...

******************************************
----- Current SQL Statement for this session (sql_id=9df852xw86wxt) -----
select avg(pk_col) from kso.little_skew where col1 = 1
*******************************************

...

SPM: cost-based plan found in the plan baseline, planId = 2333352146
SPM: fixed planId's of plan baseline are: 803197271
SPM: using qksan to reproduce, cost and select accepted plan, sig = 1872586980585244352
SPM: reproduce plan round 1, using session OFE=11010007
SPM: using qksan to reproduce accepted plan, planId = 803197271
Registered qb: SEL$1 0xf6d872ec (PARSER)
---------------------
QUERY BLOCK SIGNATURE
---------------------
  signature (): qb_name=SEL$1 nbfros=1 flg=0
    fro(0): flg=4 objn=90376 hint_alias="LITTLE_SKEW"@"SEL$1"

DOP: Automatic degree of parallelism is disabled: Parameter.
PM: Considering predicate move-around in query block SEL$1 (#0)
**************************
Predicate Move-Around (PM)
**************************
OPTIMIZER INFORMATION

******************************************
----- Current SQL Statement for this session (sql_id=7039h2744jjrv) -----
/* SQL Analyze(110,0) */ select avg(pk_col) from kso.little_skew where col1 = 1
*******************************************

...

SPM: planId in plan baseline = 803197271, planId of reproduced plan = 2333352146
------- START SPM Plan Dump -------
SPM: failed to reproduce the plan using the following info:
  parse_schema name        : SYS
  plan_baseline signature  : 1872586980585244352
  plan_baseline plan_id    : 803197271
  plan_baseline hintset    :
    hint num  1 len 27 text: IGNORE_OPTIM_EMBEDDED_HINTS
    hint num  2 len 37 text: OPTIMIZER_FEATURES_ENABLE('11.1.0.7')
    hint num  3 len 22 text: DB_VERSION('11.1.0.7')
    hint num  4 len  8 text: ALL_ROWS
    hint num  5 len 22 text: OUTLINE_LEAF(@"SEL$1")
    hint num  6 len 57 text: INDEX_RS_ASC(@"SEL$1" "A"@"SEL$1" ("LITTLE_SKEW"."COL1"))
SPM: generated non-matching plan:
----- Explain Plan Dump -----
----- Plan Table -----

============
Plan Table
============
-----------------------------------------+-----------------------------------+
| Id  | Operation           | Name       | Rows  | Bytes | Cost  | Time      |
-----------------------------------------+-----------------------------------+
| 0   | SELECT STATEMENT    |            |       |       |   907 |           |
| 1   |  SORT AGGREGATE     |            |     1 |     9 |       |           |
| 2   |   TABLE ACCESS FULL | LITTLE_SKEW|  605K | 5449K |   907 |  00:00:11 |
-----------------------------------------+-----------------------------------+
Predicate Information:
----------------------
2 - filter("COL1"=1)

Content of other_xml column
===========================
  db_version     : 11.1.0.7
  parse_schema   : SYS
  plan_hash      : 3498336203
  plan_hash_2    : 2333352146
  Outline Data:
  /*+
    BEGIN_OUTLINE_DATA
      IGNORE_OPTIM_EMBEDDED_HINTS
      OPTIMIZER_FEATURES_ENABLE('11.1.0.7')
      DB_VERSION('11.1.0.7')
      ALL_ROWS
      OUTLINE_LEAF(@"SEL$1")
      FULL(@"SEL$1" "LITTLE_SKEW"@"SEL$1")
    END_OUTLINE_DATA
  */

------- END SPM Plan Dump -------

So it appears that the Baseline is found in the SMB (SQL Management Base). It then appears to try to reproduce the plan in a separate session using the hints. It then announces that it came up with a different plan and spits out the plan data that it came up with. So it appears that the plan_hash_value is just used for comparison to see if it came up with the same plan as the one that was in place when the Baseline was generated. If not, then it falls back to the regular (no Baseline) behavior. Not at all what I had hoped for!

It may be that 11gR1 is an intermediate step and that a future version (11gR2 maybe, I hope) will actually store the plan details instead of just the plan hash value. But as I said in the intro, this is complete speculation on my part.

Category: Oracle, Plan Stability | 10 Comments

Kerry Osborne's Oracle Blog

Oracle Support Sanctions Manually Created SQL Profiles!

SQL Tuning Advisor Profiles

Single Hint SQL Profiles

Fixing Bad Index Hints in SQL Profiles (automatically)

How to Attach a SQL Profile to a Different Statement – Take 2

Why Isn’t Oracle Using My Outline / Profile / Baseline?

How to Attach a SQL Profile to a Different Statement

Oracle 11g Adaptive Cursor Sharing (ACS)

Oracle 11g SQL Plan Management – SQL Plan Baselines

Do SQL Plan Baselines Use Hints? – Take 2

Recent Posts

Recent Comments

Archives

Categories

Meta
